Trane IntelliPak CGAF Series User Manual

22
System Operating Status
1. Press the NEXT key until the following screen is displayed.
Used on Units:
With Current Sensing Module on 40-60 Ton
Possible Values:
0 to 255
1. Press the NEXT key until the following screen is displayed.
Used on Units:
With Current Sensing Module on 40-60 Ton
Possible Values:
0 to 255
1. Press the NEXT key until the following screen is displayed.
2. Pressing the NEXT key will display the beginning of
the Submenu.
3. Press the NEXT key again to advance to the following screen.
This screen is displayed when GBAS 0-5 VDC Module is installed
1. Press the ENTER key until the following screen is displayed.
2. Press the NEXT key to bypass this menu and advance to
"GBAS 0-10VDC Module Status Submenu"
Used on Units:
With GBAS 0-5VDC Module
Possible Values:
Input = 0.00 to 5.00 VDC
Assignment = Not Assigned
3. Press the NEXT key to display Generic BAS Analog Input Leaving Solution Setpoint
screens 2, 3, & 4. Ice Build Terminate Setpoint
4. Press the NEXT key to advance to the following screen. Hot Start Load Limit Setpoint
Capacity Limit Setpoint
Used on Units:
With GBAS 0-5VDC Module
Possible Values:
Open, Closed
1. Press the NEXT key until the following screen is displayed.
Used on Units:
With GBAS 0-5VDC Module
Possible Values:
Output = On, Off
Assignment = Output Is Not Assigned
2. Press the NEXT key to display Generic BAS Binary Output Indicate any comp is running
screens 2, 3, 4 & 5. Indicate unit at max capacity
3. Press the NEXT key to advance to the following screen. Indicate selected diag alarms
1. Pressing the NEXT key will display the beginning of
the Submenu.
2. Press the NEXT key again to advance to the following screen.
This screen is displayed when GBAS 0-10 VDC Module is installed
1. Press the ENTER key until the following screen is displayed.
2. Press the NEXT key to bypass this menu and advance to
"General Status" Display Screen.
Used on Units:
With GBAS 0-10 VDC Module
Possible Values:
Output = 0.00 - 10.00 VDC
Assignment = Output Is Not Assigned
3. Press the NEXT key to display Generic BAS Analog Input Leaving Solution Setpoint
screens 2, 3 & 4. Ice Build Terminate Setpoint
4. Press the NEXT key to advance to the following screen. Hot Start Load Limit Setpoint
Capacity Limit Setpoint
Compressor 2A Phase Currents - Amps
Phase B 88 Phase C 90
Compressor 2B Phase Currents - Amps
Phase A 93 Phase C 89
End of Submenu (NEXT) to Re-enter STATUS
GBAS 0-5VDC Module Status Submenu
Press ENTER to View Data in This Submenu
GBAS 0-5VDC Analog Input 1 0.00 VDC
Assigned: NOT ASSIGNED
GBAS (0-5VDC) Demand Limit Input Status
OPEN
GBAS (0-5VDC) Binary Output 1 OFF
Assigned: OUTPUT IS NOT ASSIGNED
End of Submenu (NEXT) to Re-enter STATUS
GBAS 0-10VDC Module Status Submenu
Press ENTER to View Data in This Submenu
GBAS 0-10VDC Analog Input 1 0.00 VDC
Assi
g
ned: NOT ASSIGNED
