Product Specifications
MODEL
L8V1A040U3VSBA
(a)
L8V1A060U3VSBA
(a)
L8V1B080U4VSBA
(a)
L8V1C100U5VSBA
(a)
TYPE
Upflow / Horizontal Upflow / Horizontal Upflow / Horizontal Upflow / Horizontal
RATINGS
(b)
Input BTUH 40,000 60,000 80,000 100,000
Capacity BTUH (ICS)
(c)
31,700 48,100 63,000 80,200
Temp. Rise (Min. - Max.) °F
30 - 60 30 - 60 30 - 60 30 - 60
AFUE – Rating
(c)
80 80 80 80
Return Air Temp. (Min. - Max.) °F
55°F - 80°F 55°F - 80°F 55°F - 80°F 55°F - 80°F
BLOWER DRIVE DIRECT DIRECT DIRECT DIRECT
Diameter – Width (In.)
11 X 8 11 X 8 11 X 8 11 X 10
No. Used 1 1 1 1
Speeds (No.)
Variable Variable Variable Variable
CFM vs. in. w.g.
See Fan Performance
Table
See Fan Performance
Table
See Fan Performance
Table
See Fan Performance
Table
Motor HP 0.5 0.5 0.75 1
RPM Variable Variable Variable Variable
Volts / Ph / Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 6.4 6.4 9.6 10
COMBUSTION FAN – Type Centrifugal Centrifugal Centrifugal Centrifugal
Drive – No. Speeds
Variable Variable Variable Variable
Motor RPM 4700 4700 4700 4700
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 1.00 1.00 1.00 1.00
Inducer Orifice 3.15 3.15 3.15 3.15
FILTER – Furnished? No No No No
Type recommended High Velocity High Velocity High Velocity High Velocity
High Vel. (No.-Size-Thk.)
1 - 14 X 25 - 1 in. 1 - 14 X 25 - 1 in. 1 - 16 X 25 - 1 in. 1 - 20 X 25 - 1 in.
VENT PIPE DIAMETER – Min (in.)
4 Round 4 Round 4 Round 4 Round
HEAT EXCHANGER – Type
Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Gauge (Fired)
20 20 20 20
ORIFICES – Main
Nat. Gas Qty. - Drill Size
1 - 3.2 mm 1 - #23 1 - #15 1 - #11
GAS VALVE
Redundant - Two Stage Redundant - Two Stage Redundant - Two Stage Redundant - Two Stage
PILOT SAFETY DEVICE – Type 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter
BURNERS
Type
Premix-ULN Premix-ULN Premix-ULN Premix-ULN
Quantity
1 1 1 1
POWER CONN. – V/Ph/Hz
(d)
120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
Ampacity (Amps)
9.2 9.2 13.2 13.7
Max. Overcurrent Protection (Amps)
15 15 15 15
PIPE CONN. SIZE (in.)
1/2 1/2 1/2 1/2
(a)
Central Furnace heating designs are certified to ANSI Z21.47 — latest edition.
(b)
For U.S. applications, above input ratings (BTUH) are up to 2,000 feet, derate 4% per 1,000 feet for elevations above 2,000 feet above sea level.
(c)
Based on U.S. government standard tests.
(d)
The above wiring specifications are in accordance with National Electrical Code; however, installations must comply with local codes.
