Airflow Tables
Table 3. L8V1A040U3VS Heating Airflow
L8V1A040U3VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure (iwc)
with Filter
Heating Capacity = 31,700
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating
Low 550
CFM 594 614 634 653 673
Temp. Rise
50 48 47 45 44
Watts 21 66 112 158 204
Medium Low
(a)
610
CFM 668 684 699 714 730
Temp. Rise
44 43 42 42 41
Watts 28 76 124 172 220
Medium 630
CFM 705 715 725 736 746
Temp. Rise
42 41 41 40 40
Watts 31 80 128 177 225
High
700
CFM 792 797 801 806 810
Temp. Rise
37 37 37 37 37
Watts 43 93 143 194 244
Table 4. L8V1A040U3VS Cooling Airflow
L8V1A040U3VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter
Outdoor
Tonnage - ODT
Airflow Setting
(CFM/Ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
1.5
450
CFM / WATTS 687 / 58 682 / 99 677 / 143 673 / 190 668 / 239
420
CFM / WATTS 642 / 51 638 / 90 635 / 133 632 / 178 628 / 226
400
CFM / WATTS 612 / 46 609 / 84 607 / 126 604 / 170 602 / 217
370
CFM / WATTS 566 / 40 566 / 76 565 / 116 564 / 159 563 / 205
350
CFM / WATTS 536 / 36 536 / 71 536 / 110 536 / 152 536 / 198
330
CFM / WATTS 506 / 33 507 / 67 508 / 105 509 / 146 510 / 190
310
CFM / WATTS 476 / 29 478 / 62 480 / 99 482 / 140 484 / 182
290
CFM / WATTS 446 / 26 449 / 58 452 / 94 455 / 135 458 / 178
2.0
450
CFM / WATTS 913 / 106 901 / 157 889 / 210 877 / 263 865 / 317
420
CFM / WATTS 853 / 92 843 / 139 833 / 189 822 / 241 812 / 296
400
CFM / WATTS 813 / 83 804 / 129 795 / 177 786 / 228 777 / 281
370
CFM / WATTS 752 / 70 746 / 114 739 / 160 732 / 209 725 / 260
350
CFM / WATTS 712 / 59 707 / 106 701 / 149 695 / 196 690 / 247
330
CFM / WATTS 672 / 56 668 / 96 663 / 140 659 / 186 655 / 234
310
CFM / WATTS 632 / 49 629 / 88 626 / 130 623 / 175 620 / 223
290
CFM / WATTS 592 / 43 590 / 81 588 / 122 586 / 165 585 / 211
2.5
450
CFM / WATTS 1140 / 177 1120 / 236 1101 / 297 1081 / 359 1062 / 422
420
CFM / WATTS 1064 / 151 1047 / 207 1030 / 265 1013 / 324 996 / 385
400
CFM / WATTS 1014 / 135 998 / 189 983 / 245 968 / 300 952 / 362
370
CFM / WATTS 938 / 114 925 / 164 913 / 217 900 / 272 887 / 329
350
CFM / WATTS 888 / 100 877 / 149 866 / 201 854 / 254 843 / 309
330
CFM / WATTS 838 / 88 828 / 135 818 / 185 809 / 236 799 / 290
310
CFM / WATTS 788 / 77 780 / 122 771 / 170 763 / 220 755 / 272
290
CFM / WATTS 737 / 67 731 / 110 724 / 156 718 / 204 712 / 255
3.0
(a)
450
CFM / WATTS 1366 / 273 1339 / 362 1312 / 413 1285 / 476 1259 / 553
420
CFM / WATTS 1275 / 232 1251 / 295 1228 / 361 1204 / 428 1180 / 495
400
CFM / WATTS 1215 / 207 1193 / 267 1171 / 331 1149 / 396 1127 / 461
370
CFM / WATTS 1124 / 172 1105 / 230 1087 / 290 1068 / 351 1049 / 415
350
CFM / WATTS 1064 / 151 1047 / 207 1030 / 265 1013 / 324 996 / 385
330
CFM / WATTS 1004 / 132 989 / 185 974 / 242 959 / 298 944 / 357
310
CFM / WATTS 943 / 115 930 / 166 917 / 219 904 / 275 891 / 331
290
CFM / WATTS 883 / 99 872 / 148 861 / 199 850 / 252 838 / 306
