Pump Package
The Canariis Pumping System is completely assembled and consists of two
centrifugal pumps, butterfly isolation valves, check valves, y-stainer, multi-
purpose valve, controls and piping designed to maintain a suitable water
pressure over a widely varying flow range. Maintenance, once the system is
properly installed is minimal.
Temporary Storage
If the unit will not be placed into immediate service, store in a clean dry area.
Rotate each pump shaft by hand monthly to coat the bearings with lubricant
and retard oxidation and corrosion.
Piping
Avoid any points in the piping that might create air pockets and throttle the
flows. DO NOT FORCE PIPING WHEN MAKING CONNECTIONS! Use piping
hangers or other supports. Suction piping should be independently supported
and properly aligned so that NO STRAIN IS TRANSMITTED TO THE UNIT.
Tightening Connections
All piping and wiring is factory tested. Handling during transit, off-loading and
installation can loosen the connections and the tightening of some connec-
tions may be required.
Pre-Start Review and Inspection
Before starting the system it is important to review the following information.
Each system is custom fabricated incorporating a variety of components.
The system construction, options, control sequencing panel features and
operation of your system is defined in the following pages.
A close visual inspection of the system components is recommended.
Table 20 Water Storage
Pump Package
Water Storage
Gallons (Liters) Pump Package
Water Storage
Gallons (Liters)
C2-2.5-4 13.64(51.63) E5-3-6 19.59 (74.16)
D3-2.5 - 4 13.54 (51.25) F5-4-4 23.54 (89.11)
D3-2.5-6 16.98 (64.28) F5-4-6 26.09 (98.76)
D5-3-4 16.18 (61.25) F7.5-4-4 23.54 (89.11)
E2-3-4 16.25 (61.51) F7.5-4-6 26.09 (98.76)
E3-3-4 16.25 (61.51) G3-4-4 23.62 (89.41)
E5-3-4 16.25 (61.51) G3-4-6 26.56 (100.54)
D5-3-6 19.41 (73.47) G5-4-4 23.62 (89.41)
E3-3-6 19.59 (74.16) G5-4-6 26.56 (100.54)
This is for pump package only. For evaporator water storage refer to General information
section.
C2-2.5
1
-4
2
1
Digit 17 plus in the model number.
2
Size of evap water connection.
