50 RTAA-SVX01A-EN
Installation — Electrical
Table 10 Electrical Data
Unit Wiring
Motor Data
Unit Size
Rotated
Voltage MCA (2) MOP (1)
Rec Time
Delay or
RDE (3)
Qty.
Compressor
(Ea) RLA (4) LRA (7) Qty.
Fans (Ea)
KW FLA
Control
KW (6)
RTAA 70
200/60 300 400 350 2 115/115 800/800 8 1.0 5.1 0.75
230/60 265 350 300 2 100/100 690/690 8 1.0 5.0 0.75
460/60 133 175 150 2 50/50 330/330 8 1.0 2.5 0.75
575/60 108 125 125 2 40/40 270/270 8 1.0 2.2 0.75
346/50 153 200 175 2 58/58 390/390 8 1.0 2.7 0.75
400/50 133 175 150 2 50/50 325/325 8 1.0 2.5 0.75
RTAA 80
200/60 361 500 400 2 142/142 800/800 8 1.0 5.1 0.75
230/60 319 400 350 2 124/124 760/760 8 1.0 5.0 0.75
460/60 160 200 175 2 62/62 380/380 8 1.0 2.5 0.75
575/60 131 175 150 2 50/50 304/304 8 1.0 2.2 0.75
346/50 184 250 225 2 72/72 430/430 8 1.0 2.7 0.75
400/50 160 200 175 2 62/62 375/375 8 1.0 2.5 0.75
RTAA 90
200/60 428 600 600 2 192/142 990/880 9 1.0 5.1 0.75
230/60 378 500 500 2 167/124 820/760 9 1.0 5.0 0.75
460/60 190 250 225 2 84/62 410/380 9 1.0 2.5 0.75
575/60 154 200 175 2 67/50 328/304 9 1.0 2.2 0.75
346/50 243 300 250 2 96/72 485/430 9 1.0 2.7 0.75
400/50 214 250 225 2 84/62 402/375 9 1.0 2.5 0.75
RTAA 100
200/60 483 600 600 2 192/192 990/990 10 1.0 5.1 0.75
230/60 426 500 500 2 167/167 820/820 10 1.0 5.0 0.75
460/60 214 250 250 2 84/84 410/410 10 1.0 2.5 0.75
575/60 173 225 200 2 67/67 328/328 10 1.0 2.2 0.75
346/50 243 300 300 2 96/96 485/485 10 1.0 2.7 0.75
400/50 214 250 250 2 84/84 402/402 10 1.0 2.5 0.75
RTAA 110
200/60 536 700 600 2 233/192 1190/990 10 1.0 5.1 0.75
230/60 471 600 600 2 203/167 1044/820 10 1.0 5.0 0.75
460/60 235 300 300 2 101/84 522/410 10 1.0 2.5 0.75
575/60 191 250 225 2 81/67 420/328 10 1.0 2.2 0.75
346/50 270 350 300 2 117/96 585/485 10 1.0 2.7 0.75
400/50 236 300 300 2 101/84 512/402 10 1.0 2.5 0.75
RTAA 125
200/60 576 800 700 2 233/233 1190/990 10 1.0 5.1 0.75
230/60 507 700 600 2 203/203 1044/1044 10 1.0 5.0 0.75
460/60 253 350 300 2 101/101 522/522 10 1.0 2.5 0.75
575/60 205 250 225 2 81/81 420/420 10 1.0 2.2 0.75
346/50 291 400 350 2 117/117 585/585 10 1.0 2.7 0.75
400/50 253 350 300 2 101/101 512/512 10 1.0 2.5 0.75
(1) MOP - Maximum Overcurrent Protection - may be either type breaker (UL/CSA) or with circuit breakers (CSA only). MOP = 225 percent of the largest
compressor RLA plus 100 percent of the second compressor plus the sum of the condenser fans FLAs per NEC 440-22.
(2) MCA - Minimum Circuit Ampacity - 125 percent of largest compressor RLA plus 100 percent of second compressor plus the sum of the condenser
fans FLAs per NEC 440-33.
(3) RECOMMENDED TIME DELAY OR DUAL ELEMENT (RDE) FUSE SIZE: 150 percent of the largest compressor RLA plus 100 percent of the
second compressor RLA and the sum the condenser fan FLAs.
(4) RLA -Rated Load Amps -rated in accordance with UL Standard 465.
(5) Local codes may take precedence.
(6) Control kw includes operational controls only. Does not include heat tapes.
(7) LRA - Locked Rotor Amps -based on full winding start units.
(8) VOLTAGE UTILIZATION RANGE:
Rated Voltage Utilization Range
200/60 180-220
230/60 208-254
460/60 414-506
575/60 516-633
400/50 340-460
(9) 60 HZ UNITS - A 115/60/1, 15 amp. customer provided power connection is required to power the evaporator heat tape 420 watts
(10) 50 HZ UNITS - A separate 220/50/1 15 amp. customer provided power connection is needed to power evaporator heat tape 420 watts @ 220 volts.
