RTAA-SVX01A-EN 17
Installation — Mechanical
Lifting Procedure
CAUTION
Equipment Damage!
To prevent damage do not use a forklift to lift or push the unit.
Position lifting beam so that cables do not contact the unit.
• Install chains and safety chains through the six lifting plates provided on
the unit.
• Attach lifting chains or cables to the chains installed above. Each cable
alone must be strong enough to lift the chiller.
• Attach cables to lifting beam. Total lifting weight, lifting weight distribution
and required lifting beam dimensions are shown in Figure 4 and Figure 5
and on the rigging diagram shipped with each unit. Lifting beam cross-
bars must be positioned so lifting cables do not contact the sides of the
unit.
