Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Partial Heat Recovery
Heat recovery option is made with a plate heat exchanger in series with the air-cooled condenser. This heat
exchanger benefits the discharge gas superheat as well as a part of the condensing gas heat to be transferred to hot
water system.
PHR General data
General Data Partial Heat Recovery (PHR) RTAF with Fix Speed Compressor - R134a
PHR RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 140 145 150 155 170 175 185 190
Efciency Level(s) SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE
Heating capacity (1)
Gross heating Capacity (1) (kW) 82 94 110 127 131 136 141 146 154 164 169
Condenser
Type Stainless steel Copper Brazed plate Heat exchanger
Circuit 1 BPHE
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
Circuit 2 BPHE
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm
Water content volume (l) 10.0 10.0 10.0 10.0 10.0 12.0 12.0 12.0 12.0 12.0 12.0
PHR RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
200 205 245 250 280 310 350 355 380 410 450
Efciency Level(s) SE/HE/XE SE/HE/XE SE/HE/XE SE SE SE SE SE SE SE SE
Heating capacity (1)
Gross heating Capacity (1) (kW) 177 183 198 215 244 269 299 294 331 362 398
Condenser
Type Stainless steel Copper Brazed plate Heat exchanger
Circuit 1 BPHE
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
Circuit 2 BPHE
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
70pl
B3-095
40pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm
Water content volume (l) 12.0 12.0 12.0 30.0 30.0 30.0 35.0 30.0 35.0 35.0 35.0
General Data Partial Heat Recovery (PHR) RTAF with Variable Speed Compressor (with VFD) - R134a
PHR RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 145 155 175 190 205
Efciency Level(s) HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS
Heating capacity (1)
Gross heating Capacity (1) (kW) 83 96 113 133 144 160 174 187
Condenser
Type Stainless steel Copper Brazed plate Heat exchanger
Circuit 1 BPHE
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
Circuit 2 BPHE
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
28pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm
Water content volume (l) 10.0 10.0 10.0 10.0 12.0 12.0 12.0 12.0
PHR RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
245 250 280 310 350 380 410 450
Efciency Level(s) HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS HSE/HSS
Heating capacity (1)
Gross heating Capacity (1) (kW) 218 221 250 280 312 340 369 399
Condenser
Type Stainless steel Copper Brazed plate Heat exchanger
Circuit 1 BPHE
B3-095
40pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
Circuit 2 BPHE
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
40pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
B3-095
70pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm 2” - 50mm
Water content volume (l) 12.0 30.0 30.0 30.0 35.0 35.0 35.0 35.0
(1) Indicative performance at Evaporator water temperature : 12°C/7°C - Condenser air temperature 35°C - Condenser water temperature 40°C/45°C .
For accurate value refer to OWU.
