Trane Sintesis RTAF HE series User Manual

RLC-SVX19G-GB
121
11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Total Heat Recovery
THR General data
General Data Total Heat Recovery (THR) RTAF with Fix Speed Compressor - R1234ze
THR RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 100 110 120 130 145 155 185
Efciency Level(s) SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE
Heating capacity
Gross heating Capacity (1) (kW) 379 415 452 486 522 573 635 742
Condenser
Type Stainless steel Copper Brazed plate Heat exchanger
Circuit 1 BPHE B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 176pl B56N-W 176pl
Circuit 2 BPHE B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 112pl B56N-W 176pl B56N-W 176pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
4'' - 100mm 4'' - 100mm 4'' - 100mm 4'' - 100mm 4'' - 100mm 4'' - 100mm 5'' - 125mm 5'' - 125mm
Water content volume (l) 95.0 95.0 95.0 95.0 95.0 95.0 128.0 128.0
Antifreeze Heater (W) 900.0 900.0 900.0 900.0 900.0 900.0 900.0 900.0
BPHE heaters (W) 132.0 132.0 132.0 132.0 132.0 132.0 132.0 132.0
THR RTAF RTAF RTAF RTAF RTAF RTAF
210 230 265 285 305 340
Efciency Level(s) SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE SE/HE/XE
Heating capacity (1)
Gross heating Capacity (kW) 845 948 1105 1163 1268 1484
Condenser - Water Cooled (THR)
Type Stainless steel Copper Brazed Plates Heat Exchanger
Circuit 1 BPHE B427L 318pl B427L 318pl B427L 318pl B427L 318pl B427L 318pl B427L 318pl
Circuit 2 BPHE B56N-W 176pl B56N-W 176pl B56N-W 176pl B427L 318pl B427L 318pl B427L 318pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
6" - 150mm 6" - 150mm 6" - 150mm 6" - 150mm 6" - 150mm 6" - 150mm
Water content volume (l) 200 200 200 230 230 230
Antifreeze Heater (W) 900 900 900 900 900 900
BPHE heaters (W) 165 165 165 200 200 200
THR General data
General Data Total Heat Recovery (THR) RTAF with Variable Speed Compressor - R1234ze
THR RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 100 110 120 130 145 155 185 200 225 101
Efciency Level(s)
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
Heating capacity (1)
Gross heating Capacity (kW) 377 415 452 488 525 577 643 746 746 1035 1034
Condenser
Type Stainless steel Copper Brazed plate Heat exchanger
Circuit 1 BPHE
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
Circuit 2 BPHE
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
112pl
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
4'' -
100mm
4'' -
100mm
4'' -
100mm
4'' -
100mm
4'' -
100mm
4'' -
100mm
5'' -
125mm
5'' -
125mm
5'' -
125mm
5'' -
125mm
5'' -
125mm
Water content volume (l) 95.0 95.0 95.0 95.0 95.0 95.0 128.0 128.0 128.0 128.0 128.0
Antifreeze Heater (W) 900.0 900.0 900.0 900.0 900.0 900.0 900.0 900.0 900.0 900.0 900.0
BPHE heaters (W) 132.0 132.0 132.0 132.0 132.0 132.0 132.0 132.0 132.0 132.0 132.0
THR RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
210 230 265 275 285 300 305 340 385 405 470
Efciency Level(s)
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
HSS/
HSE
Heating capacity (1)
Gross heating Capacity (kW) 848 955 1107 1165 1240 1291 1394 1485 1622 1783 2139
Condenser - Water Cooled (THR)
Type
Circuit 1 BPHE
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
Circuit 2 BPHE
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
B56N-W
176pl
B427L
318pl
B56N-W
176pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
B427L
318pl
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
6" -
150mm
Water content volume (l) 200 200 200 200 230 200 230 230 230 230 230
Antifreeze Heater (W) 900 900 900 900 900 900 900 900 900 900 900
BPHE heaters (W) 165 165 165 165 200 165 200 200 200 200 200
(1) Indicative performance at Evaporator water temperature : 12°C / 7°C - Condenser air temperature 35°C - Condenser water temperature 40°C/45°C .
For accurate value refer to OWU.
(2) Data may vary according to compressor selection for a given tonage.
