Trane Sintesis RTAF HE series User Manual

RLC-SVX19G-GB
125
11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Optional Free-Cooling
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 145 155 175 185 190 200 205
Partial Free Cooling type
Coils quantity (5) # 4 4 4 6 6 6 6 6 6 6
Coils quantity (6) # 4 4 4 6 6 6 / 6 / 6
Summer nominal water ow (L/s) 15.1 17.5 20.3 24.3 26.1 28.7 30.7 31.5 33.2 34.2
Summer & Winter unit pressure drop (kPa) 51 57 58 82 88 65 NA 77 NA 75
Glycol Pump Max Power input (kW) (kW) 4.0 4.0 4.0 4.0 4.0 5.5 5.5 5.5 5.5 5.5
Glycol Pump Max Amps @ 110 V (A) 7.8 7.8 7.8 7.8 7.8 10.2 10.2 10.2 10.2 10.2
Freeze protection - Max Power input kW 0.66 0.66 0.66 0.66 0.66 0.72 0.72 0.72 0.72 0.72
Freeze protection - Max Amps A 1.65 1.65 1.65 1.65 1.65 1.80 1.80 1.80 1.80 1.80
Additional Free Cooling weight
(without water) (5)
(kg) 777 777 789 928 928 1027 1027 1023 1027 1023
Additional Free Cooling weight
(without water) (6)
(kg) 785 785 801 918 924 1023 / 1019 / 1019
Additional water content (without Evap.) (5) (L) 54 54 73 73 73 90 90 90 90 90
Additional water content (without Evap.) (6) (L) 785 785 801 918 924 1023 / 1019 / 1019
Glycol content (5) (L) 175 175 173 219 219 239 239 238 239 238
Glycol content (6) (L) 279 279 283 342 342 345 / 396 / 396
Additional baseframe length (5) (m) 1.125 1.125 1.125 / / / / / / /
Additional baseframe length (6) (m) / / / / / / / / / /
(1) SE-SN/HE-SN/HE-LN
(2) SE-LN/XE-SN/XE-LN/HSS-SN/HSS-LN/HSE-SN/HSE-LN
(3) SE-XLN/XE-XLN/HSS-SN/HSS-XLN/HSE-XLN
(4) Max Speed - range is 60% to 100% of max speed
(5) SE-SN/SE-LN/SE-XLN/HSS-SN/HSS-LN/HSS-XLN
(6) HE-SN/HE-LN/XE-SN/XE-LN/XE-XLN/HSE-SN/HSE-LN/HSE-XLN
Table 24a – General data for free cooling option sizes 090- 205 - R134a (continued)
