RLC-SVX19G-GB
45
11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
General Data
Table 11a – General Data RTAF 090-245 High Seasonal Efficiency Short - Standard and Low Noise - R134a - R513A
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 140 145 150 155 170 175 185 190 200 205 245 (9)
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
Cooling Capacity (1) (kW) 330 378 443 509 526 545 567 582 617 656 676 706 731 839
Unit electrical data (2) (3) (4)
Maximum Power input in cooling (kW) 140 161 190 219 223 242 246 265 269 292 296 315 319 339
Unit rated amps (Max compr
+Fan+Control)
(A) 214 247 290 334 340 369 375 404 410 445 451 481 487 516
Unit start up amps (Starting Amps
of the largest compr+RLA of 2nd
compr+RLA of all fans+ control)
(A) 214 247 290 334 340 369 375 404 410 445 451 481 487 516
Displacement Power Factor (DPF) 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95
Max power cable cross section (mm
2
) 1x240 1x240 1x240 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300
Disconnect switch size (A) 400 400 500 630 630 630 630 630 630 800 800 800 800 800
Compressor
Quantity # 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Type Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw
Model (9) 45/45 50/50 70/50 70/70 70/70 85/70 85/70 85/85 100/70 100/85 100/85 100/100 100/100 120/120
Max Compr Power input
Circuit 1/Circuit 2
kW 61/61 72/72 101/72 101/101 101/101 124/101 124/101 124/124 147/101 147/124 147/124 147/147 147/147 156/156
Max Amps Circuit 1 / Circuit 2 (3) (4) (A) 93/93 110/110 153/110 153/153 153/153 188/153 188/153 188/188 224/153 224/188 224/188 224/224 224/224 236/236
Start up Amps Circuit 1 / Circuit 2
(3) (4)
(A) 93/93 110/110 153/110 153/153 153/153 188/153 188/153 188/188 224/153 224/188 224/188 224/224 224/224 236/236
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit 1 / Circuit 2 (W) 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150
Evaporator
Quantity # 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 115B 115A 165B 165B 165B 165A 165A 200B 200B 200B 200B 250C 250C 250B
Evaporator Water Content volume (l) 51 58 74 74 74 78 78 99 99 99 99 109 109 118
Antifreeze Heater (W) 1640 1640 1640 1640 1640 1640 1640 2040 2040 2040 2040 2040 2040 2040
Two pass evaporator
Evap. Water Flow rate - Minimum (l/s) 8.0 9.4 11.6 11.6 11.6 12.4 12.4 14.2 14.2 14.2 14.2 16.2 16.2 17.9
Evap. Water Flow rate - Maximum (5) (l/s) 29.6 34.7 43.1 43.1 43.1 46.0 46.0 52.6 52.6 52.6 52.6 60.3
60.3 66.5
Nominal water connection size
(Grooved coupling)
(in) -
(DN)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150
Two pass evaporator with turbulator
Evap. Water Flow rate - Minimum (5) (l/s) 6.6 7.8 9.7 9.7 9.7 10.3 10.3 11.8 11.8 11.8 11.8 13.5 13.5 14.9
Evap. Water Flow rate - Maximum (l/s) 26.6 31.2 38.7 38.7 38.7 41.3 41.3 47.2 47.2 47.2 47.2 54.1 54.1 59.7
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Available Head Pressure (1) (kPa) 141 128 142 121 121 179 179 NA 172 153 153 148 148 148
Max Motor Power input (kW) 5.5 5.5 7.5 7.5 7.5 11.0 11.0 NA 11.0 11.0 11.0 11.0 11.0 11.0
Max Amps (A) 11 11 14 14 14 21 21 NA 21 21 21 21 21 21
High head pressure pump option (Twin Pump)
Available Head Pressure (1) (kPa) 253 239 224 NA 245 NA 237 NA 230 264 264 259 259 259
Max Motor Power input (kW) 11.0 11.0 11.0 NA 15.0 NA 15.0 NA 15.0 18.5 18.5 18.5 18.5 18.5
Max Amps (A) 21 21 21 NA 28 NA 28 NA 28 35 35 35 35 35
Expansion Tank Volume (l) 80 80 80 NA 80 NA 80 NA 80 80 80 80 80 80
Max User water loop Volume for
factory mounted expansion tank (1)
(l) 6000 6000 6000 NA 6000 NA 6000 NA 6000 6000 6000 6000 6000 6000
Max. Water-side Operating Pressure
without pump package
(kPa) 1000 1000 1000 NA 1000 NA 1000 NA 1000 1000 1000 1000 1000 1000
Max. Water-side Operating Pressure
with pump package
(kPa) 450 450 450 NA 450 NA 450 NA 450 450 450 450 450 450
Antifreeze Heater with pump package (W) 2360 2360 2360 2360 2360 2360 2360 2760 2760 2760 2760 2760 2760 2760
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity # 4/4 4/4 4/4 4/4 5/5 4/4 5/5 4/4 6/4 5/5 6/6 5/5 6/6 6/6
Face area per coil (m²) 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan
Quantity # 4/4 4/4 4/4 4/4 5/5 4/4 5/5 4/4 6/4 5/5 6/6 5/5 6/6 6/6
Diameter (mm) 800 800 800 800 800 800 800 800 800 800 800 800 800 800
Standard / High ambient fan option
Fan / motor Type Propeller fan / Variable speed - EC motor
Airow per Fan (m
3
/h) 15000 17400 17400 17400 17400 17400 17400 20000 20000 20000 20000 20000 20000 20000
Max Power input per Motor (kW) 0.6 0.9 0.9 0.9 0.9 0.9 0.9 1.3 1.3 1.3 1.3 1.3 1.3 1.3
Max Amps per Motor (A) 1.1 1.6 1.6 1.6 1.6 1.6 1.6 2.3 2.3 2.3 2.3 2.3 2.3 2.3
Motor RPM (rpm) 710 810 810 810 810 810 810 910 910 910 910 910 910 910
