Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Table 17b – General Data RTAF 210-340 High Efficiency - AC Extra Low Noise - R1234 ze
RTAF RTAF RTAF RTAF RTAF RTAF
210 230 265 285 305 340
HE AC XLN HE AC XLN HE AC XLN HE AC XLN HE AC XLN HE AC XLN
Net Cooling Capacity (1) (kW) 726 820 892 1006 1094 1201
Unit electrical data (2) (3) (5)
Maximum Power input in cooling (kW) 346 403 403 479 533 538
Unit rated amps (Max compr+Fan+Control) (A) 580 668 668 802 884 890
Unit start up amps (Starting Amps of the largest compr (A) 730 818 818 952 1034 1040
Displacement Power factor (DPF) 0.86 0.87 0.87 0.87 0.87 0.87
Max Power cable cross section mm
²
4*185 4*185 4*185 4*185 4*185 4*185
Disconnect switch size (A) 1250 1250 1250 1250 1250 1250
Compressor
Quantity # 3 3 3 4 4 4
Type Screw Screw Screw Screw Screw Screw
Model 65-78/65 78-78/78 78-78/78 65-78/65-78 78-78/78-78 78-78/78-78
Max Compr Power input Circuit1 / Circuit2 (kW)
98-125/
98
125-125/
125
125-125/
125
98-125/
98-125
125-125/
125-125
125-125/
125-125
Max Amps Circuit1 / Circuit 2 (3) (5) (A)
163-204/
163
204-204/
204
204-204/
204
163-204/
163-204
204-204/
204-204
204-204/
204-204
Start up Amps Circuit1 / Circuit 2 (3)(5) (A)
291-354/
354
354-354/
354
354-354/
354
291-354/
291-354
354-354/
354-354
354-354/
354-354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit1 / Circuit 2 (W) 700 700 700 850 850 850
Evaporator
Quantity # 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 300E 300D 300D 500E 500D 500D
Evaporator Water Content volume (l) 86 97 97 130 146 146
Antifreeze Heater (W) 2240 2240 2240 2440 2440 2440
Two pass evaporator
Evap. Water Flow rate - Minimum (l/s) 15.7 17.7 17.7 22.2 25.0 25.0
Evap. Water Flow rate - Maximum (6) (l/s) 58.5 65.8 65.8 82.6 92.8 92.8
Nominal water connection size (Grooved coupling) (in) - (mm) 6" - 150 6" - 150 6" - 150 8" - 200 8" - 200 8" - 201
Two pass evaporator with turbulator
Evap. Water Flow rate - Minimum (l/s) 13.2 14.8 14.8 18.5 20.8 20.8
Evap. Water Flow rate - Maximum (6) (l/s) 52.5 59.1 59.1 74.2 83.4 83.4
Nominal water connection size (Grooved coupling) (in) - (mm) 6" - 150 6" - 150 6" - 150 8" - 200 8" - 200 8" - 201
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Available Head Pressure (1) (kPa) N/A N/A N/A N/A N/A N/A
Max. Motor Power Input (kW) 11.0 11.0 15.0 15.0 15.0 22.0
Max. Rated Amps (A) 20.8 20.8 29.0 29.0 29.0 39.7
High head pressure pump option (Twin pump) N/A N/A N/A N/A N/A N/A
Available Head Pressure (1) (kPa) N/A N/A N/A N/A N/A N/A
Max. Motor Power Input (kW) 18.5 18.5 22.0 22.0 22.0 0.0
Max. Amps (A) 34.5 34.5 39.7 39.7 39.7 0.0
Expansion Tank Volume (l) N/A N/A N/A N/A N/A N/A
Max User water loop Volume for factory mounted expansion tank (1) (l) N/A N/A N/A N/A N/A N/A
Max. Water-side Operating Pressure without pump package (kPa) N/A N/A N/A N/A N/A N/A
Max. Water-side Operating Pressure with pump package (kPa) N/A N/A N/A N/A N/A N/A
Antifreeze Heater with pump package (W) 3300 3300 3400 3600 3600 3600
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity # 12/4 12/6 12/6 12/10 12/10 12/12
Face area per coil (m²) 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan
Quantity # 12/4 12/6 12/6 12/10 12/10 12/12
Diameter (mm) 800 800 800 800 800 800
Standard / High ambient fan option
Fan / motor Type Propeller fan / Fixed speed - AC motor
Airow per Fan (m³/h) 18000 18000 18000 18000
18000 18000
Max Power Input per Motor (kW) 1.2 1.2 1.2 1.2 1.2 1.2
Max Amps per Motor (A) 2.9 2.9 2.9 2.9 2.9 2.9
Motor RPM (rpm) 900 900 900 900 900 900
