Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
General Data
Table 18a – General Data RTAF 250-450 Extra Efficiency - Standard and Low Noise - R134a - R513A
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
250 280 310 350 355 380 410 415 450
XE SN LN XE SN LN XE SN LN XE SN LN XE SN LN XE SN LN XE SN LN XE SN LN XE SN LN
Cooling Capacity (1) (kW) 876 990 1107 1237 1218 1359 1463 1479 1606
Unit electrical data (2) (3) (5)
Maximum Power input in cooling (kW) 374 424 485 530 544 580 625 625 704
Unit rated amps (Max compr +Fan+Control) (A) 620 700 802 874 900 958 1036 1037 1169
Unit start up amps (Starting Amps of the largest
compr+RLA of 2nd compr+RLA of all fans+ control)
(A) 773 853 916 1027 982 1111 1150 1151 1251
Displacement Power Factor (DPF) 0.87 0.88 0.88 0.88 0.87 0.88 0.87 0.87 0.87
Max power cable cross section (mm
2
) 4x185 4x185 4x185 4x185 4x185 4x185 4x185 4x185 6x185
Disconnect switch size (A) 1250 1250 1250 1250 1250 1250 1250 1250 1600
Compressor
Quantity # 3 3 3 4 3 4 4 4 4
Type Screw Screw Screw Screw Screw Screw Screw Screw Screw
Model (9)
85-85/
70
85-100/
85
100-100/
100
85-85/
85-85
115-115/
115
85-100/
85-100
100-100/
100-100
100-100/
100-101
115-115/
115-115
Max Compr Power input Circuit 1/Circuit 2 kW
121-121/
99
121-144/
121
144-144/
144
121-121/
121-121
164-164/
164
121-144/
121-144
144-144/
144-144
144-144/
144-144
164-164/
164-164
Max Amps Circuit 1 / Circuit 2 (3) (5) (A)
201-201/
166
201-240/
201
240-240/
240
201-201/
201-201
273-273/
273
201-240/
201-240
240-240/
240-240
240-240/
240-240
273-273/
273-273
Start up Amps Circuit 1 / Circuit 2 (3) (5) (A)
354-354/
291
354-354/
354
354-354/
354
354-354/
354-354
354-354/
354
354-354/
354-354
354-354/
354-354
354-354/
354-354
354-354/
354-354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit 1 / Circuit 2 (W) 300/150 300/150 300/150 300/300 300/300 300/300 300/300 300/300 300/300
Evaporator
Quantity # 1 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 300D 300B 300A 500D 300A 500C 500B 500B 500B
Evaporator Water Content volume (l) 97 108 120 146 120 159 170 170 170
Antifreeze Heater (W) 2240 2240 2240 2440 2440 2440 2440 2440 2440
Two pass evaporator
Evap. Water Flow rate - Minimum (l/s) 17.7 20.1 22.8 25.0 22.8 27.8 30.3 30.3 30.3
Evap. Water Flow rate - Maximum (6) (l/s) 65.8 74.5 84.8 92.8 84.8 103.0 112.5 112.5 112.5
Nominal water connection size (Grooved coupling)
(in) -
(DN)
6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 200 8" - 200 8" - 200
Two pass evaporator with turbulator
Evap. Water Flow rate - Minimum (6) (l/s) 14.8 16.7 19.0 20.8 19.0 23.1 25.3 25.3 25.3
Evap. Water Flow rate - Maximum (l/s) 59.1 66.9 76.1 83.4 76.1 92.5 101.1 101.1 101.1
Nominal water connection size (Grooved coupling)
(in) -
(mm)
6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 200 8" - 200 8" - 200
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Available Head Pressure (1) (kPa) 160 106 115 139 82 127 116 116 77
Max Motor Power input (kW) 15
15 15 22 15 22 22 22 22
Max Amps (A) 28 28 28 39.7 28 39.7 39.7 39.7 39.7
High head pressure pump option (Twin Pump)
Available Head Pressure (1) (kPa) 216 220 174 NA 175 NA NA NA NA
Max Motor Power input (kW) 18.5 22 22 NA 22 NA NA NA NA
Max Amps (A) 34.5 39.7 39.7 NA 39.7 NA NA NA NA
Expansion Tank Volume (l) 80 160 160 160 160 160 160 160 160
Max User water loop Volume for factory mounted
expansion tank (1)
(l) 40000 8000 8000 8000 8000 8000 8000 8000 8000
Max. Water-side Operating Pressure without pump
package
(kPa) 1000 1000 1000 1000 1000 1000 1000 1000 1000
Max. Water-side Operating Pressure with pump
package
(kPa) 450 450 450 450 450 450 450 450 450
Antifreeze Heater with pump package (W) 3300 3400 3400 3600 3400 3600 3600 3600 3600
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity # 12/4 12/6 14/6 12/10 14/6 12/12 12/12 12/12 12/12
Face area per coil (m²) 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan
Quantity # 12/4 12/6 14/6 12/10 14/6 12/12 12/12 12/12 12/12
Diameter (mm) 800 800 800 800 800 800 800 800 800
Standard / High ambient fan option
Fan / motor Type Propeller fan / Variable Speed - EC motor
Airow per Fan (m
3
/h) 20000 20000 20000 20000 20000 20000 20000 22500 20000
Max Power input per Motor (kW) 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.9 1.3
Max Amps per Motor (A) 2.3 2.3 2.3 2.3 2.3 2.3 2.3 3.0 2.3
Motor RPM (rpm) 910 910 910 910 910 910 910 1020 910
