RLC-SVX19G-GB
83
11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Table 20b – General Data RTAF 210-405 High Seasonal Efficiency Short - Standard and Low Noise - R1234 ze
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
210 230 265 275 285 300 305 340 385 405
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
HSS SN
LN
Net Cooling Capacity (1) (kW) 727 809 887 999 998 1105 1085 1188 1310 1426
Unit electrical data (2) (3) (5)
Maximum Power input in cooling (kW) 379 421 425 468 511 515 554 558 605 652
Unit rated amps (Max compr+Fan+Control) (A) 591 656 662 727 807 799 872 878 949 1021
Unit start up amps (Starting Amps of the largest
compr
(A) 741 806 812 877 957 949 1022 1028 1099 1171
Displacement Power factor (DPF) 0.93 0.93 0.93 0.93 0.92 0.93 0.92 0.92 0.92 0.92
Max Power cable cross section mm
²
4*185 4*185 4*185 4*185 4*185 4*185 4*185 4*185 4*185 6*185
Disconnect switch size (A) 1250 1250 1250 1250 1250 1250 1250 1250 1250 1600
Compressor
Quantity # 3 3 3 3 4 3 4 4 4 4
Type Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw
Model (9)
65-78/
65
78-78/
78
78-78/
78
78-78/
78
65-78/
65-78
78-78/
78
78-78/
78-78
78-78/
78-78
78-78/
78-78
78-78/
78-78
Max Compr Power input Circuit1/ Circuit2 (kW)
112-125/
112
134-125/
134
134-125/
134
155-125/
155
112-125/
112-125
179-125/
179
134-125/
134-125
134-125/
134-125
155-125/
155-125
179-125:
179-125
Max Amps Circuit1 / Circuit 2 (3) (4) (A)
171-204/
171
203-204:
203
203-204/
203
236-204/
236
203-204/
203-204
271-204/
271
203-204/
203-204
203-204/
203-204
236-204/
236-204
271-204/
271-204
Start up Amps Circuit1 / Circuit 2 (3)(4) (A)
171-354/
171
203-354/
203
2036354/
203
239-204/
236
171-354/
171-354
271-354/
271
203-354/
203-354
203-354/
203-354
236-354/
236-354
271-354/
271-354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit1 / Circuit 2 (W) 700 700 700 700 850 700 850 850 850 850
Evaporator
Quantity # 1 1 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 300E 300D 300D 300B 500E 300B 500D 500D 500C 500B
Evaporator Water Content volume (l) 86 97 97 108 130 108 146 146 159 170
Antifreeze Heater (W) 2240 2240 2240 2240 2440 2240 2440 2440 2440 2440
Two pass evaporator
Evap. Water Flow rate - Maximum (6) (l/s) 15.7 17.7 17.7 20.1 22.2 20.1 25.0 25.0 27.8 30.3
Evap. Water Flow rate - Maximum (l/s) 58.5 65.8 65.8 74.5 82.6 74.5 92.8 92.8 103.0 112.5
Two pass evaporator with turbulator (in) - (mm) 6" - 150 6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 201 8" - 200 8" - 200
Two pass evaporator with turbulator
Evap. Water Flow rate - Maximum (6) (l/s) 13.2 14.8 14.8 16.7 18.5 16.7 20.8 20.8 23.1
25.3
Evap. Water Flow rate - Maximum (l/s) 52.5 59.1 59.1 66.9 74.2 66.9 83.4 83.4 92.5 101.1
Nominal water connection size (Grooved
coupling)
(in) - (mm) 6" - 150 6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 201 8" - 200 8" - 200
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Max. Motor Power Input (kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Motor Power (kW) 11.0 11.0 15.0 15.0 15.0 15.0 15.0 22.0 22.0 22.0
High head pressure pump option (Twin pump) (A) 20.8 20.8 29.0 29.0 29.0 29.0 29.0 39.7 39.7 39.7
High head pressure pump option (Twin pump) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Motor Power Input (kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Amps (kW) 18.5 18.5 22.0 22.0 22.0 22.0 22.0 0.0 0.0 0.0
Max. Rated Amps (A) 34.5 34.5 39.7 39.7 39.7 39.7 39.7 0.0 0.0 0.0
Expansion Tank Volume (l) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max User water loop Volume for factory mounted
expansion tank (1)
(l) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Water-side Operating Pressure without
pump package
(kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Water-side Operating Pressure with pump
package
(kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Antifreeze Heater with pump package (W) 3300 3300 3400 3400 3600 3400 3600 3600 3600 3600
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity # 10/4 10/4 10/6 10/6 10/8 10/6 10/8 10/10 12/10 12/10
Face area per coil (m²) 2.4 2.4 2.4 3.4 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan
Quantity # 10/4 10/4 10/6 10/6 10/8 10/6 10/8 10/10 12/10 12/10
Diameter (mm) 800 800 800 800 800 800 800 800 800 800
Standard / High ambient fan option
Fan / motor Type Propeller fan / Variable speed - EC motor
Max Power Input per Motor (m³/h) 20000 20000 20000 20000 20000 20000 20000 20000 20000 20000
Max Amps per Motor (kW) 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3
Motor RPM (A) 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3
Rated motor RPM (rpm) 910 910 910 910 910 910 910 910 910 910
General Data
