Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Table 22b – General Data RTAF 210-470 & 141-191 High Seasonal Efficiency - Standard and Low Noise - R1234 ze
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
210 230 265 275 285 300 305 340 385 405 470 141 191
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
HSE SN
LN
Net Cooling Capacity (1) (kW) 732 828 896 1006 1112 1013 1105 1206 1317 1433 1694
Not suitable for
comfort application
Unit electrical data (2) (3) (5)
Maximum Power input in cooling (kW) 382 429 429 472 519 523 562 566 609 656 763 511 644
Unit rated amps (Max
compr+Fan+Control)
597 668 668 733 819 811 884 890 955 1027 1161 793 1009
Unit start up amps (Starting
Amps of the largest compr
(A) 747 818 818 883 969 961 1034 1040 1105 1177 1161 943 1159
Displacement Power factor
(DPF)
(A) 0.93 0.93 0.93 0.93 0.92 0.93 0.92 0.92 0.92 0.92 0.95 0.93 0.92
Max Power cable cross section (mm²) 4*185 4*185 4*185 4*185 4*185 4*185 4*185 4*185 4*185 6*185 6*185 4*185 6*185
Disconnect switch size (A) 1250 1250 1250 1250 1250 1250 1250 1250 1250 1600 1600 1250 1600
Compressor
Quantity # 3 3 3 3 4 3 4 4 4 4 4 3 3
Type Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw
Model (9)
65-78/
65
78-78/
78
78-78/
78
78-78/
78
65-78/
65-78
78-78/
78
78-78/
78-78
78-78/
78-78
78-78/
78-78
78-78/
78-78
78-78/
78-78
78-78/
78
78-78/
78-78
Max Compr Power input
Circuit 1 / Circuit 2
(kW)
112-125/
112
134-125/
134
134-125/
134
155-125/
155
112-125/
112-125
179-125/
179
134-125/
134-125
134-125/
134-125
155-125/
155-125
179-
125:179-
125
179-179/
179-179
179-125/
179
179-125/
179-125
Max Amps Circuit 1 / Circuit 2
(3) (4)
171-204/
171
203-
204:203
203-204/
203
236-204/
236
203-204/
203-204
271-204/
271
203-204/
203-204
203-204/
203-204
236-204/
236-204
271-204/
271-204
271-271/
271-271
271-204/
271
271-204/
271-204
Start up Amps
Circuit 1 / Circuit 2 (3)(4)
(A)
171-354/
171
203-354/
203
2036354/
203
239-204/
236
171-354/
171-354
271-354/
271
203-354/
203-354
203-354/
203-354
236-354/
236-354
271-354/
271-354
271-271/
271-271
271-354/
271
271-354/
271-354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater
Circuit 1 / Circuit 2
(W) 700 700 700 700 850 700 850 850 850 850 850 700 850
Evaporator
Quantity # 1 1 1 1 1 1 1 1 1
1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 300E 300D 300D 300B 500E 300B 500D 500D 500C 500B 500N 300E 500E
Evaporator Water Content
volume
(l) 86 97 97 108 130 108 146 146 159 170 188 86 130
Antifreeze Heater (W)
Two pass evaporator
Evap. Water Flow rate -
Maximum (6)
(l/s) 15.7 17.7 17.7 20.1 22.2 20.1 25.0 25.0 27.8 30.3 30.3 15.7 22.2
Evap. Water Flow rate -
Maximum
(l/s) 58.5 65.8 65.8 74.5 82.6 74.5 92.8 92.8 103.0 112.5 112.5 58.5 82.6
Two pass evaporator with
turbulator
(in) -
(mm)
6" - 150 6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 201 8" - 200 8" - 200 8" - 200 6" - 150 8" - 200
Two pass evaporator with turbulator
Evap. Water Flow rate -
Maximum (6)
(l/s) 13.2 14.8 14.8 16.7 18.5 16.7 20.8 20.8 23.1 25.3 25.3 13.2 18.5
Evap. Water Flow rate -
Maximum
(l/s) 52.5 59.1 59.1 66.9 74.2 66.9 83.4 83.4 92.5 101.1 101.1 52.5 74.2
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
6" - 150 6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 201 8" - 200 8" - 200 8" - 200 6" - 150 8" - 200
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Max. Motor Power Input (kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Motor Power (kW) 11.0 11.0 15.0 15.0 15.0 15.0 15.0 22.0 22.0 22.0 0.0 15.0 15.0
High head pressure pump
option (Twin pump)
(A) 20.8 20.8 29.0 29.0 29.0 29.0 29.0 39.7 39.7 39.7 0.0 29.0 29.0
High head pressure pump
option (Twin pump)
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Motor Power Input (kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Amps (kW) 18.5 18.5 22.0 22.0 22.0 22.0 22.0 0.0 0.0 0.0 0.0 18.5 22.0
Max. Rated Amps (A) 35 35 40 40 40 40 40 0 0 0 0 35 40
Expansion Tank Volume (l) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max User water loop Volume
for factory mounted expansion
tank (1)
(l) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Water-side Operating
Pressure without pump package
(kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Max. Water-side Operating
Pressure with pump package
(kPa) N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Antifreeze Heater with pump
package
(W) 3300 3300 3400 3400 3600 3400 3600 3600 3600 3600 3600 3300 3600
