Triumph Sprint ST User Manual

24
General Information
Speedometer
The speedometer indicates the road speed of
the motorcycle.
Tachometer
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). On the
right side of the tachometer face is the
'red zone'. Engine rpm (r/min) in the red
zone is above maximum recommended
engine speed and is also above the range for
best performance.
Odometer/Trip Meter
1. Odometer/Trip meter display
2. Set button
3. Trip button
The odometer shows the total distance that
the motorcycle has travelled.
The odometer and two trip meters are
located in the same LCD display as the clock
and trip computer. Either trip meter shows
the distance that the motorcycle has travelled
since the meter on display was last reset to
zero.
Use the 'trip' button to switch between the
odometer and trip meter display modes.
Press the 'trip' button repeatedly until the
desired display is visible. The display will scroll
through in the order:
•Odometer
• Trip Meter 1
• Trip Meter 2
To reset either of the trip meters, select and
display the trip meter to be zeroed then press
the 'trip' button for 2 seconds. After
2 seconds, the trip meter on display will reset
to zero.
Warning
Never allow engine rpm to enter the
'red zone' as severe engine damage may
result.
km/h
12 3
ccqu
Warning
Do not attempt to switch between
odometer and trip meter display modes or
reset the trip meter with the motorcycle in
motion as this may lead to loss of
motorcycle control and an accident.
