Triumph Trident User Manual

MAINTENANCE
116
1
2
chbe_2
1. Carrier plate
2. Brake pad lining
Brake pads for this model supplied by
Triumph will have the carrier plate at
the recommended thickness. Always
have replacement brake pads supplied
and installed by your Triumph dealer.
If the lining thickness of any brake pad
is less than that specified in the table,
replace all the brake pads on the wheel.
Minimum Brake Pad Lining
Thickness
0.06in (1.5
mm)
Minimum Carrier Plate Thickness
0.16in (4.0
mm)
Minimum Service Thickness
(Brake Pad Lining and Carrier
Plate)
0.22in (5.5
mm)
Rear Brake Wear Inspection
Warning
If installing new proprietary brand
brake pads, check that the brake
backing plate of the brake pad is the
specified thickness shown in the table.
Installing brake pads with the brake
backing plate less than the specified
thickness may result in brake failure
due to the possible loss of the brake
pad as it wears.
2
1
1. Carrier plate
2. Brake pad lining
Brake pads supplied by Triumph will
have the carrier plate at the
recommended thickness. Always have
replacement brake pads supplied and
installed by your Triumph dealer.
If the lining thickness of any brake pad
is less than that specified in the table,
replace all the brake pads on the wheel.
Minimum Brake Pad Lining
Thickness
0.06in (1.5
mm)
Minimum Carrier Plate Thickness
0.12in (3.0
mm)
Minimum Service Thickness
(Brake Pad Lining and Carrier
Plate)
0.18in (4.5
mm)

Triumph Trident Specifications

General

Engine Capacity	660 cc
Transmission	6-speed
Seat Height	805 mm
Dry Weight	189 kg
Frame	Tubular steel perimeter frame
Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Max Power	81 hp (60.5 kW) @ 10, 250 rpm
Max Torque	47 lb-ft (64 Nm) @ 6, 250 rpm
Rear Suspension	Showa monoshock, preload adjustable
Front Brakes	Twin 310mm discs, Nissin 2-piston sliding calipers, ABS
Rear Brakes	Nissin single-piston sliding caliper, single 255mm disc, ABS
Fuel Tank Capacity	14 Litres
Front Suspension	Showa 41mm upside down separate function forks (SFF)
