2 Design
2.1 Pin description
Provide clean and stable supply.
Assure a good GND connection to all GND pins of the module,
preferably with a large ground plane.
It is recommended to connect a backup supply voltage to V_BCKP in
order to enable warm and hot start features on the positioning
modules. Otherwise, connect to VCC.
To use the USB interface, connect this pin to 3.0 ā 3.6 V.
If no USB serial port used connect to GND.
GNSS signal
input from
antenna
The connection to the antenna must be routed on the PCB. Use a
controlled impedance of 50 ļ to connect RF_IN to the antenna or
the antenna connector.
Output Voltage
RF section
VCC_RF can be used to power an external active antenna.
Communication interface,
Can be programmed as TX_READY for DDC interface.
If pin 2 low => SPI MISO.
Serial input. Internal pull-up resistor to VCC. Leave open if not used.
If pin 2 low => SPI MOSI.
USB bidirectional communication pin. Leave open if unused.
TIMEPULSE
TIMEPULSE
1 (NEO-M8T)
Configurable Timepulse signal (one pulse per second by default).
Leave open if not used.
SAFEBOOT_
N
TP2/SAFEB
OOT_N
(NEO-M8T)
Configurable Timepulse2 signal
SAFEBOOT_N, leave open if not used. Do not pull low during reset.
External Interrupt Pin.
Internal pull-up resistor to VCC. Leave open if not used. Function is
disabled by default.
RESERVED
EXTINT1
(NEO-M8T)
External Interrupt Pin.
Internal pull-up resistor to VCC. Leave open if not used. Function is
disabled by default.
DDC Data
If pin 2 low => SPI chip select.
DDC Clock.
If pin 2 low => SPI clock.
Antenna control can be used to turn on and off an optional external
LNA.
Allow selecting UART/DDC or SPI
open-> UART/DDC; low->SPI
Table 2: NEO-8Q and NEO-M8 series Pinout
