UNI-T UT60F User Manual

Display Symbols(1) (see figure 2)
13
Number Symbol Meaning
Indicator for DC voltage or current1 DC
Indicator for AC voltage or current2 AC
The Meter is in the auto range
mode in which the Meter autom
atically selects the range with the
best resolution.
AUTO
3
Data output is in progress
4 RS232C
Data hold is active
5
Test of diode
6
The continuity buzzer is on
7
The unit of temperature:
Centigrade temperature
Fahrenheit temperature
8
Farad. The unit of capacitance
nF: Nanofarad. 1x10
-9
or
0.000000001 farads.
µF:Microfarad.1x10
-6
or
0.000001 farads.
mF: Millifarad. 1x10
-3
or
0.001 farads.
9
nF,µF,
mF
o
C
o
F
Model UT60F/G: OPERATING MANUAL
( figure 2)
n mF
µ
C F
1
2
14
15
16
3
4 5 6
7
8
9
10/11
12/13
DC
AC
mVA
Mk Hz
µ
Ω
RS232C
