Unitech PA600 Getting Started

Chapter 3 Getting Connected
28
Copyright 2008 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
Synchronizing with the Computer
Synchronization occurs according to the options setup in Microsoft ActiveSync via the
computer. Accepting the default (On Connect) synchronization option in the Microsoft
ActiveSync Setup Wizard enables users to simply connect the PA600 to the desktop
computer and synchronization will automatically occur.
If the On Connect feature in Microsoft ActiveSync is not selected, start Microsoft
ActiveSync through either of the following:
• On the computer, double-click My Computer → Mobile Devices folder.
• Connect the USB Cable between the computer and PA600.
Connection options
Set remote synchronization with the computer through following connection options:
• USB connection.
• Bluetooth connection.
• GPRS connection.
• Wi-Fi connection.
USB Connection
Synchronize the computer via a USB connection through the following:
1. Connect the PA600 to a computer using the USB Charging Cable.
2. Tap Start → Programs → ActiveSync.
3. Tap Menu → Connections....
4. Select Synchronize all PCs using this con-
nection check box.
5. Select a baud rate or cable type connection.
6. Tap OK.
Bluetooth Connection
The PA600 is equipped with Bluetooth wireless technology that can synchronize infor-
mation with a computer equipped with a Bluetooth adapter or access point. Bluetooth
wireless technology communicates with the computer whenever it is within range.
Setup a Bluetooth connection through the following:

Unitech PA600 Specifications

System Memory

SDRAM memory	64 MB
Flash ROM	128 MB
Flash ROM with WWAN	320 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	Yes

Power

main battery	3.7V 1950mAh Li-Ion Battery Pack
backup battery	One Rechargeable Ni-MH Backup Battery
power source	Main Battery

Operating Environment

operating temperature	32ºF to 122ºF (0ºC to 50ºC)
storage temperature	-4ºF to 140ºF (-20ºC to 60ºC)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight	290g with Battery & Scan Engine
length	149.5 mm
height	26.6 mm
