Unitech PA600 Getting Started

Chapter 5 Advanced Settings
46
Copyright 2008 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
Performing a Cold Boot
A cold boot cuts off power from the PA600, erasing all records and entries, deleting all
added programs, and restoring the PA600 to default factory settings.
Data and time settings are not retained in a cold boot while formats, preferences and
other settings restore to their default factory settings. Not even data stored in Flash
Storage is retained.
NOTE: Only perform a hard reset unless a soft reset does not correct the prob-
lem. Data can restore through the next Microsoft ActiveSync operation,
or it can transfer from a storage card.
Perform a cold boot through the following:
1. Press TAB.
2. While holding TAB, insert the tip of the
Stylus into the Reset Button on the
PA600’s back panel. Press and hold the
Reset Button until the Unitech logo
appears onscreen. Wait five seconds
and then release TAB.
NOTE: The system returns to the default settings. All registry settings and all
files (including hidden files) return to their original factory defaults.
FUNC
Ls
ESC ghi jkl mno
wxyz
ENTER
TAB
tuvpqrs
key
OK
abc Rs def
ALPHA
1
4
7
2
5
8
0
3
6
9
.

Unitech PA600 Specifications

System Memory

SDRAM memory	64 MB
Flash ROM	128 MB
Flash ROM with WWAN	320 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	Yes

Power

main battery	3.7V 1950mAh Li-Ion Battery Pack
backup battery	One Rechargeable Ni-MH Backup Battery
power source	Main Battery

Operating Environment

operating temperature	32ºF to 122ºF (0ºC to 50ºC)
storage temperature	-4ºF to 140ºF (-20ºC to 60ºC)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight	290g with Battery & Scan Engine
length	149.5 mm
height	26.6 mm
