RUNNING
GEAR
Rugged (Tourist &
Sportsman)
Cruiser Models
Frame Tubular welded
Rear wheel
suspension
Swing arm with
hydraulic
spring shock absorbers
Sidecar: Same
Solo: Lower spring
rate
Front fork
Leading link for the
sidecar
model
Telescopic spring
Sidecar
Cushioned body (on
rubber cushions) and
wheel on long-lever
suspension with
hydraulic spring shock
absorber
NA on solo
Brakes
Shoe-type with mechanical drive on front, rear
and sidecar wheels, front wheel has dual
cams.
Tires
4"x19" Rugged &
Cruiser
Front & Side: 22 psi
cold
Rear: 36 psi cold
3.5" x 18" Cruiser
(-10)
Front & Side 25 psi
cold
Rear: 36 psi cold
3.5" x 18" SOLO
Front: 25 psi cold
Rear: 32 psi cold
CLEARANCES
mm in
Valves with engine cold 0.05 0.002
Between spark plug
electrodes
0.50 - 0.65 0.020 - 0.026
Between brake shoes and
drum
0.3 - 0.70 0.012 - 0.028
Backlash between tooth
faces of bevel gears in final
drive
0.1 - 0.3 0.004
Between rotor and ignition
pickup
0.3 - 0.4 .012 - .016
