shoes are interchangeable with the motorcycle brake shoes.
The rear wheel brake is mounted in the final drive case.
Figure 30. Fron
Wheel Brake
1 - Top brake lever 9 - Brake lever spring
2 - Inspection hole plug 10 - Adjusting screw
3 - Brake shoe 11 - Tie rod
4 - Adjusting bolt locknut 12 - Locknut
5 - Adjust bolt 13 - Tie rod fork
6 - Brake shoe springs 14 - Pin
7 - Front brake cam 15 - Brake drum cover
8 - Bottom brake lever
Figure 31. Sidecar Wheel Brake
