Chapter 1 (Specifications)
Torque Specifications
Metric (in repair
manual)
US Equivalent Location on Bike
29 to 33 Nm 22 ft/lb to 25 ft/lb cylinder heads
22 to 25 kgf-m 175 ft/lb to 185 ft/lb fly wheel tightening screws
3.8 to 4.2 kgf-m 30 ft/lb to 40 ft/lb cylinder
2.1 to 3.0 kgf-m top 14 ft/lb to 22 ft/lb shock absorber
3.6 to 5.0 kgf-m bottom 28 ft/lb to 36 ft/lbs shock absorber
3.0 to 3.4 kgf-m 22 ft/lb to 26 ft/lb bearing nut
3.0 to 3-4 kgf-m 22 ft/lb to 26 ft/lbs final drive to swing arm bolts
1.6 to 1.8 kgf-m 12 ft/lb to 14 ft/lb oil pump bolt
.8 to 1.0 kgf-m 5 ft/lb to 8 ft/lb engine sump
1.4 to 1.8 kgf-m 10 ft/lb to 14 ft/lb final drive case nuts
7 to 9 kgf-m 50 ft/lb to 66 ft/lb
nut fastening the pinion
bearing
2.2 to 2.8 kgf-m 16 ft/lb to 20 ft/lb reverse gear brake lever
1.8 to 2.0 kgf-m 14 ft/lb to 16 ft/lb generator gear nut
14 to 16.8 kgt-m 100 ft/lb to 120 ft/lb steering stem nut
