Clutch Dry double-disk clutch
Gearbox
4 speed box with reverse gear (no reverse for solo
model) and gear shifting foot pedal
GEAR RATIOS
TOURIST/SPORTSMAN SOLO* -10 Mdls
I gear 3.6 3.6
II gear 2.28 2.28
III gear 1.7 1.7
IV gear 1.3 1.3
Reverse gear 4.2
N/A on Solo
4.2 on -10 mdls
Speedometer drive ratio 0.4 0.5
Final drive Pair of bevel gears with propeller shaft
Final drive ratio 4.62 3.89*
*On sidecar models delivered to high altitude locations, (above 2,500 ft.) the
carburetor jetting is leaner and the rear axle gear ratio is always 4.62 not
3.89. This is necessary to accommodate the reduced air pressure and
engine power at higher altitudes.
FLUID
CAPACITIES
Tourist & -10
Models
Sportsman Solo
Gasoline tank 19 L / 5 Gal 19L / 5 Gal 18.5 L / 4.9 Gal
Reserve 2L / 0.5 gal 2L / 0.5 gal 2 L- / 0.5 Gal
Engine crankcase
2 L / 2 qt. +
3.6oz.
2L / 2 qt +3.6 oz 2 L / 2 qt. + 3.6oz.
Gearbox 0.9L / 1 qt 0.9L / 1 qt 0.9L / 1 qt
Final drive 110 ml / 3.85 oz. 150 ml / 5.25 oz. 110ml / 3.85oz
Telescopic Forks N/A on Tourist N/A on Sportsman 135ml / 4.56 oz.
(-10 & solo models) 135ml / 4.56 oz.
Air cleaner 50 ml / 1.75 oz 50 ml / 1.75 oz 50 ml / 1.75 oz
Shock Absorbers 105 ml / 3.55 oz. 105 ml / 3.55 oz. 105 ml / 3.55 oz.
