urmet domus 2VOICE 1083/48 User Manual

11
DS1083-180
REAR VIEW (IN COMMON TO BOTH MODULES)
10 11 12 151413 16
10.Congurationbutton(PROGRAM);
11.Connectorforhearingaidcoil(ILA)Ref.1168/48
12.(*)Trimmerforadjustingspeakervolume(RV1)
13.Moduleconnectionwireconnector(OUT)
14.LabelwithMACADDRESSofthedevice
15.Jumperprovidedtoconnectthedoorstatesensor
16.Terminalboard
(*) Based on the device version, the trimmer may not be available. In this case, to implement the audio
adjustment, refer to the Advanced conguration booklet by scanning the QR Code in the Advanced
conguration chapter.
4. DESCRIPTION OF TERMINALS
]
PA
Hall button
]
LINE
Bus line in
]
SE2
Garagerelaycontacts
SE -
Pedestrianelectricallockwithcapacitancedischargeactuationnegative
SE +
Pedestrianelectricallockwithcapacitancedischargeactuationpositive
5. ESSENTIAL PARAMETER CONFIGURATION (WITHOUT WiFi
CONNECTION)
5.1. CONFIGURABLE PARAMETERS
TheessentialparameterscanbecongureddirectlyonthedoorunitwithoutneedingaWiFiconnection.
Thecongurationisperformeddirectlyonthedevice.Theparameterslistedbelowcanbeconguredand
thevaluecanbesetbymeansofLEDs(1)and(4).
5.1.1. PARAMETER 1: door unit type
Thisparameterisusedtosetthedooraudioandaudio-videodoorunitasprimaryorsecondary.Allthe
usersinthesystemmaybecalledfromthemaindoorunit.Asecondarydoorunitmayonlycalltheusersof
therisertowhichitbelongs.Userswhoreceivethecallcanidentifythesourceofthecallbythetone.
5.1.2. PARAMETER 2: door unit ID
Ifmaindoorunittypeissetunderpreviousparameter,thisparametercanbeusedtochangetheIDfrom0
to1becausevariousmaincallingstationswithdierentIDcanbepresentinthesystem.
If,ontheotherhand,a“secondary”doorunittypeissetunderpreviousparameter(whichbydefaultis
namedriser0),thisparametercanbeusedtochangetheIDfrom0to1becausetwosecondarycalling
stationswithdierentIDcanbepresentinthesameriser.
