13. CONNECTION EXAMPLE
Rearviewofthemodulesxedtothepanelframeintippedposition.
14. TECHNICAL SPECIFICATIONS
Powervoltage: ..................................................................................................................................36-48 V
Consumption@48Vdc:
 Standby: .................................................................................................................................... < 10 mAcc
Full rate: .................................................................................................................................... < 250 mAcc
Frequencyband: .............................................................................................................. 2400 ÷ 2483,5 MHz
Outputpower(Max): ............................................................................................................................ 20 dBm
Wires with cross-section area of 0.5 mm
2
/ AWG20 or larger must comply with IEC 60332-1-2;
wires with crosssection area smaller than 0.5 mm
2
/ AWG20 must comply with IEC 60332-2-2.
15. KEY TO SYMBOLS
Symbol Description
Directinputvoltage
Seetheinstallationmanualofthedevice
16. SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby,URMETS.p.A.declaresthattheradioequipmenttypes:
AUDIO VIDEO EXTERNAL UNIT Ref. 1083/48 and EXTERNAL LOUDSPEAKER UNIT Ref. 1083/38
areincompliancewithDirective2014/53/EU.
ThefulltextoftheEUdeclarationofconformityisavailableatthefollowinginternetaddress:www.urmet.com
A
8 cm/ 3.1”  longcord provided
with button module with
expansion unit Ref. 1168/4 and
1168/8 of the ILA and voice
synthesis module Ref. 1168/48
andofthedoornumbermodule
Ref.1168/50.
B
82cm/32.2”cordprovidedwith
ILAand voicesynthesis module
Ref.1168/48.
C
38cm/14.9”longcordprovided
with two-module frame Ref.
1168/62 and with casing
with two-module frame Ref.
1168/312.
58cm/22.8”longcordprovided
withthreeorfour-moduleframe
Ref. 1168/63 or 1168/64) and
of one-row casings with three
or four-module frame (Ref.
1168/313 or 1168/314).
