urmet domus alpha 1168/1 User Manual

17
DS1168-014
3.6.4
According to the selected input type, one of the two screens shown by the side
appears on the display:
3.6.5
A page containing an error message will appear on the display for two seconds if
an incorrect code is entered.
3.7 OPENING THE DOOR USING A TRANSPONDER KEY
3.7.1
Pass the transponder key near the reader on the key reader module Ref. 1168/45
near the sensor in the middle of the module.
3.7.2
Press the shortcut menu next to the icon to open the door. Press the
button next to the icon to open the gate.
If the key is valid, the calling module will activate the opening of the door or gate;
one of the two warning messages shown on the side appears on the display.
3.7.3
The message shown here by the side will appear on the display for two seconds
if the key is not valid (not registered).

urmet domus alpha 1168/1 Specifications

General

Brand	urmet domus
Model	alpha 1168/1
Category	Monitor
Language	English
