PaX-Primo
20
25
WRENCH BOLT
8*20( ASSEMBLING COLUMN TO
HANDLE FRAME )
2
26 WRENCH BOLT 6*10 3
27 SCREW(FLAT HEAD)
4*16( FOR EXPOSURE SWITCH
HOLDER )
8
28 TRUSS BOLT 4*8( FOR ASSEMBLING CASE ) 10
30 SILICON CAP (WHITE/GRAY) 6EA/2EA
31 JUMP CABLE 1
33 SERIAL CABLE 1
34 CABLE TIE 10
35 LAN CABLE 1
36 SERIAL CONNECT CABLE 1
Parts lists for the Touch pad screen wall mounted type
Parts lists for the PaX-Primo wall mounted type
1-3
WALL BRACKET 1 ,2- SPC 4.0T (ZnW)
1
32
BOLT SET( WALL-MOUNTED
TYPE )
M6*15( BOLT, FLAT&SPRING
WASHER)
1 SET
2.2. Tools required
1. cross screw driver 2. flat head screw driver
3. wrench set 4. Spirit level
10
BKT_PRIMO_LCD_WALL_1,2 N10 FOR WALL-MOUNTED LCD 1 SET
20 CAP_HOLE_L 1
21 CABLE ( A WALL-MOUNTED LCD ) 1
29
PAD WASHER BOLT- M3*12 (+)
(NYLOK)
3*12( FOR WALL-MOUNTED
LCD )
4
