indication is triggered. Any values not confirmed with [OK] will
not be saved.
5.2 Overview
Continuously measuring sensors for level and pressure have
various functions. Hence they can be adapted in an optimum
way to the respective application. The functions are structured
in a clear menu form (see section "Menu schematics").
The following functions are described in this operating
instructions manual:
l General functions
l Functions for 4 … 20 mA/HART
l Functions for Profibus PA
l Functions for Foundation Fieldbus
Further, sensor-specific functions are described in the
operating instructions manual of the respective sensor.
5.3 General functions
The general functions are described in this paragraph. The
functions of the indicating/adjustment module are determined
by the sensor and correspond to the respective software
version of the sensor.
Information:
The respective menu item number differs depending on the
sensor type and signal output.
The following presentations are available in the measured
value display:
l Level as digital value, sensor TAG
l Level as digital value and bar graph, sensor TAG
l Only with pressure transmitters: Level or pressure as
digital value, temperature value
With [->] you select the different presentations of the
measured value. You can reach the menu overview from any
presentation with [OK]. With [ESC] you return from the menu
overview to the measured value display.
In the menu overview you select the appropriate menu with [->]
and open it with [OK]. Then the individual menu items are
available.
Measured value indication
Menu overview
12 Indicating and adjustment module PLICSCOM
Setup
27835-EN-070123
