7
3 Product description
VEGATOR 141 •
46838-EN-210714
3 Product description
3.1 Conguration
The scope of delivery encompasses:
•
Controller VEGATOR 141
•
Documentation
– This operating instructions manual
– Ex-specic"Safety instructions"(withExversion)
– SafetyManual"Functionalsafety(SIL)acc.toIEC61508"(with
SIL version)
– Ifnecessary,furthercerticates
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument:
•
Instrument type
•
Information about approvals
•
Technical data
•
Serial number of the instrument
•
QR code for device documentation
•
Manufacturer information
Moveto"www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Thereyoucanndthefollowinginformationabouttheinstrument:
•
Order data
•
Documentation
•
Software
Alternatively,youcanndallviayoursmartphone:
•
Scan the QR-code on the type label of the device or
•
Enter serial number manually in the VEGA Tools app (available
free of charge in the respective stores)
3.2 Principle of operation
The VEGATOR 141 is a single-channel controller for level detection
with 4 … 20 mA sensors. Simple monitoring and control functions can
be realised via the integrated relay. Typical applications are monitoring
functionssuchasoverllanddryrunprotection.Anoptionalfailsafe
relay is also available.
The VEGATOR 141 controller powers the connected sensors and
simultaneously processes their measuring signals. Each input is
continuously monitored for line break or short-circuit. In addition, fault
messages delivered by the sensor are processed.
The current of a connected 4 … 20 mA sensor is measured and
evaluated. The switching point of the relay can be adjusted to any in-
dividual current by using the potentiometer. The output relay switches
when this current is reached (in dependence on the set mode).
Scope of delivery
Type label
Documents and software
Application area
Functional principle
