1. Audio Output
Audio Output, connect the digital piano to an external amplifying system.
2. Audio Input
Audio Input, connect the digital piano to an internal amplifying system.
3. USB
USB MIDI jack
4. Pedal
Connect with piano pedal.
Note: When connecting a headphone the internal loudspeakers will be deactivated.
The volume master setting button can adjust headphone volume.
Rear Panel Function
USB
Pedal
Output
R L/Mono L/Mono
Input
R
