6
ASSEMBLY
Head
Connector
Head
Sock
et
Alignment P
in
Securing Screw
Insert the Head
Connector in the Head
Socket. Place the Head
on to the Zoom/Focus
Assembly, ensuring th
e
alignment pin in the
Zoom/Focus Assembly
lines up with the releva
nt
slot in the Head. Tighten
the securing screw.
ATTACHING HEAD
Securing
Screws
Objective
Le
n
s
6 P
o
int
Ring Light
Beam
Converger
(only for 1.5x or 2x lens)
Place the
ringlight
into position and tighten the
securing screws. Cl
ip the Beam Converger (on
ly
required if using a 1.5x or
2x objective lens) i
nto
place and attach the fibre optic ca
ble to the
illuminator.
ATTACHING
6 POINT
RINGLIGHT
Objective
Le
n
s
Le
n
s
Securing Screw
OBJECTIVE LENS
11
13
Table of Contents
Table of Contents
5
Packing Contents
7
Head Pack
7
Stand Pack or Platform Pack
7
Zoom Assembly Pack & Accessories
8
Assembly
9
Platform/Bench Assembly
9
Head to Tubular Support Assembly
9
Column to Stand Assembly
10
Column Attachment Assembly
11
Attaching Head
12
Objective Lens
12
Attaching 6 Point Ringlight
12
Attaching Spot Illuminator
13
Photographic Attachments
13
Zoom Multiplier
14
Mains Connection
14
Inserting Graticule
14
Operator Controls
15
Main System Controls
15
Graticule Adjustment
15
General Maintenance Points
16
Sub-Stage Lamp Changing
17
Illuminator Lamp Changing
17
Routine Maintenance
16
