ROUTINE
MAINTENANCE
Page
11
ROUTINE MAINTENANCE
Condenser &
Diffuser
Plate
Sub-
S
tage
Illuminator Bulb
20W/12V
Dichroic L
amp
(2000 hour)
2
3
1
150W/21V
Halogen L
amp
(200 hour)
NOTE:
ENSURE THE ILLUMINATOR
IS NOT HOT.
Press down the bulb/fan
assembly release button (see
1 above).
Lift out the bulb/fan assembly
(see 2 above).
Disconnect the lamp as
shown in 3 above.
When relocating a lamp,
ensure it is fully pus
hed into
the lamp holder.
SUB-STAGE LAMP CHANGING
ILLUMINATOR
LAMP
CHANGING
NOTE:
The 250W
Halogen lamp
version (60 hours)
has the same
lamp change
procedure
16
18
Table of Contents
Table of Contents
5
Packing Contents
7
Head Pack
7
Stand Pack or Platform Pack
7
Zoom Assembly Pack & Accessories
8
Assembly
9
Platform/Bench Assembly
9
Head to Tubular Support Assembly
9
Column to Stand Assembly
10
Column Attachment Assembly
11
Attaching Head
12
Objective Lens
12
Attaching 6 Point Ringlight
12
Attaching Spot Illuminator
13
Photographic Attachments
13
Zoom Multiplier
14
Mains Connection
14
Inserting Graticule
14
Operator Controls
15
Main System Controls
15
Graticule Adjustment
15
General Maintenance Points
16
Sub-Stage Lamp Changing
17
Illuminator Lamp Changing
17
Routine Maintenance
16
