User Manual VAS 5054A V1.06 All rights reserved. Page 35
VAS 5054A User Manual
7 Appendix
7.1 VAS 5054A Specifications
Dimensions Approx. 114 x 48 x 25 mm
Weight Approx. 100 g, with USB cable approx. 120g
Color RAL 7021
Power supply 8 ... 18V via vehicle diagnostic connector
Current consumption Approx. 200 mA at 12V
PC interface Bluetooth V1.2 Class 2 (range approx. 10 m)
USB V2.0 Full Speed, 12 Mbits/s, mini USB jack (type B)
Vehicle interface Diagnostic connector in acc. with ISO 15031-3 or SAE J1962
CAN One CAN 2.0B channel with CAN high-speed physical bus in acc. with
ISO 11898-2 and CAN low-speed physical bus in acc. with ISO 11898-3
ISO 9141-2 K- and L-line for 12V vehicle systems
SAE J1850 SAE J1850 PWM and VPW
Digital input For ignition-on signal (KL15)
Power save mode Automatic power off after a settable time, power-on by ignition
Temperature range Operation: 0...+50 °C
Storage: -25...+85 °C
7.2 Status Display
The VAS 5054A is provided with a status indicator which shows the status of communication
with the application PC via USB or Bluetooth.
In the case of a connection failure to the application PC, the indicator flashes every second. As
soon as a connection to the PC has been established, the status indicator is on continuously.
During data exchange via Bluetooth or USB, the status indicator flashes according to data
volume.
