7.3 Pin Assignment of the Vehicle Connector
The vehicle signals of the VAS 5054A are assigned to the 16-pin male connector in accordance
with SAE-J1962 and ISO 15031-3.
8 7 6 5 4 3 2 1
16 15 14 13 12 11 10 9
No. Signal name
1 KL15 (switched vehicle battery voltage)
2 J1850-P
3 n.c.
4 KL31 vehicle ground
5 KL31 vehicle ground
6 CAN-H (high-speed CAN)
7 ISO-K
8 CAN-H (low-speed CAN)
9 CAN-L (low-speed CAN)
10 J1850-N
11 n.c.
12 n.c.
13 n.c.
14 CAN-L (high-speed CAN)
15 ISO-L
16 KL30 vehicle battery voltage
n.c. not connected
