82
Maintenance. Reverse gear
Oil. Change
1. Remove the dipstick. Connect a hose from the oil
scavenging pump to the dipstick tube.
2. Suck the oil up and put the dipstick back.
3. Fill up with oil to the correct level. Oil grade and vol-
ume: Please refer to the “Technical Data” chapter.
IMPORTANT! Never over-fill the reverse
gear.
4. Start the engine and run until the reverse gear
has reached operating temperature.
5. Check the oil level, as in the description on the
previous page.
Seal. Lubrication
Applies only to TwinDisc reverse gear
Lubricate theseal on the output shaft bearing (with
the lubricating nipple) using a hand gun and lithium-
based grease such as Mobilux EP2, Statoil Uniway
EP2N, Texaco Multifak EP2, Q8 Rembrandt EP2.
