Volvo V50 2012 User Manual

TP 39212202 C30/S40 (04-)/V50/C70 (06-) 2012 202
64/10B C70
6-pin gray
No. Roof harness Floor harness
1 4/56H:21 Central Electronic Module
(CEM)
OG-YE
63/218 Branching point
OG-YE
2 4/56H:17 Central Electronic Module
(CEM)
WH-RD
63/217 Branching point
WH-RD
33/117:9Switch unit, ceiling light
BK-YE
63/212 Branching point
BK-YE
4 4/56H:20 Central Electronic Module
(CEM)
BK
64/41:10 Connector
64/43:10 Connector
BK
54/56D:4Central Electronic Module
(CEM)
OG-BU
64/70:1 Connector
OG-BU
6-
-
-
64/25G
10-pin gray
No. Dashboard harness Tunnel harness
1 4/56A:23 Central Electronic Module
(CEM)
GY
9/1:2 Outlet 12V front
GY
263/25 Branching point
BK
3/286:5 Switch BLIS/PAS/DRIVe
9/1:1 Front 12 V outlet C30
63/86B Branching point C70
BK
364/545:1Connector
BU-YE
3/286:1 Switch BLIS/PAS/DRIVe
BU-YE
464/112:7Connector
64/545:3 Connector
WH
3/286:3 Switch BLIS/PAS/DRIVe
WH
5- -
-
616/1A:8Integrated Audio Module
(IAM)
-
-
-
716/1A:14Integrated Audio Module
(IAM)
RD-BK
17/40:2 Auxiliary equipment input (AUX)
RD-BK
816/1A:7Integrated Audio Module
(IAM)
BU-GN
17/40:4 Auxiliary equipment input (AUX)
BU-GN
916/1A:9Integrated Audio Module
(IAM)
BU-RD
17/40:1 Auxiliary equipment input (AUX)
BU-RD
10 - -
64/27
5-pin gray
No. Dashboard harness Tunnel harness
116/1D:1Integrated Audio Module
(IAM)
BK
17/42:1 USB-port
BK
216/1D:2Integrated Audio Module
(IAM)
VT
17/42:2 USB-port
VT
316/1D:3Integrated Audio Module
(IAM)
BN
17/42:3 USB-port
BN
416/1D:4Integrated Audio Module
(IAM)
RD
17/42:4 USB-port
RD
516/1D:5Integrated Audio Module
(IAM)
-
17/42:5 USB-port
-
Connectors
64/10B - 64/27
