TP 39212202 C30/S40 (04-)/V50/C70 (06-) 2012 24

Relays

Ignition switch and relays

Relays, general

The diagram indicates two or three different designations for the relay’s position. This

is described below.

A = Corresponds to the position on the back

of the relay box (wiring side)

B = Corresponds to the position on the relay

C = An old designation that may be found on

the relay

ABC

2(85)

5(87)

1(86)

4(87a)

3(30)

G041236

Default Chapter2
- Vehicles with SRS (Airbag)/Sips Bag/IC (Inflatable Curtain)2
