TP 39212202 C30/S40 (04-)/V50/C70 (06-) 2012 31
31/3 Left MacPherson strut tower
1/1 Battery
7/240 Battery monitoring sensor (BMS)
31/4 Engine
1/1 Battery
7/240 Battery monitoring sensor (BMS)
31/6 A-post, driver’s side
3/111 Switch unit, lights
4/93 Keyless Vehicle Module (KVM), RHD
4/102 Steering Column Lock Module (SCL)
10/1 Lamp housing, front left
10/2 Lamp housing, front right
17/13 Data link connector
7/238 Alcohol lock
31/10 A-post, passenger side
2/16 Relay, rear window wiper
2/23 Relay, fuel pump
2/63 Relay, high beam
2/64 Relay, auxiliary lights
2/89 Relay, interior lighting
2/92 Relay, windshield washer motor
2/93 Relay, rear window washer motor
2/159 Relay, infotainment
2/193 Relay, comfort functions
3/25 Switch, power roof/sunroof
3/112 Climate Control Module (CCM)
3/117 Switch unit, ceiling light
3/156 Gear Selector Module (GSM)
3/173 Switch, trunk lid/tailgate private lock
3/286 Switch BLIS/PAS/DRIVe
4/33 Sunroof control module
4/56 Central Electronic Module (CEM)
6/2 Washer pump
6/48 Damper Motor Module (DMM), recirculation
6/95 Damper Motor Module (DMM), temperature, left side
6/96 Damper Motor Module (DMM), temperature, right side
6/102 Damper Motor Module (DMM), defroster
6/103 Damper Motor Module (DMM), floor/ventilation
6/117 Interior temperature sensor
7/149 Rain Sensor Module (RSM)
7/159 Air Quality Sensor (AQS)
8/48 Auto-dimming rearview mirror
8/134 Solenoid, reverse interlock, manual
9/1 Front 12V outlet
9/25 Rear 12V outlet
Continues
Ground connections
31/3 - 31/10 cont
