Instruments and Controls 95
Changing Telltale Bulbs In Cluster
NOTE! Before beginning to work, make
sure the vehicle ignition is switched OFF.
If possible, adjust the steering column
back. Remove the two screws at the top of
the instrument cluster and fold the cluster
out and let it rest face-down against the
steering column so the bulbs are accessible.
CAUTION
Do not let the cluster be in the
face-down position for more than maxi-
mum 15 minutes. Damage to the gauges
can occur by oil running out of them,
making the gauge reading inaccurate.
W3000842
Do not use any other tools for changing the
bulbs than the correct tool. Using a pair of
pliers could easily cause a short-circuit if
power is on, thereby destroying the circuit
board.
W3001306
