Graphic Display 115
Graphic Display Controls
If the vehicle is in motion, use the dis-
play controls carefully. Do not lose road
concentration. Be familiar with operation
of the controls. Shifting concentration to
operating the controls can lead to losing
control of the vehicle and may result in
serious personal injury or death.
The controls for the graphic display are lo-
cated on the windshield wiper lever on the
right-hand side of the steering wheel. The
following commands are available:
1 “Esc” is used to return to the previous
menu and cancel a setting/operation.
2 “Select” confirms a highlighted selec-
tion of a menu or character.
3 “Up arrow” moves the cursor up. Used
when setting numerical values.
4 “Down arrow” moves the cursor down.
Used when setting numerical values.
T3008810
Selecting a Menu
1 Using the up/down buttons the cursor
is moved to the particular menu,
which is then highlighted. A down ar-
row in the lower right-hand corner
shows whether there are any more
menus available. If this is the case,
you can continue to step down through
the list (see the adjacent example).
2 Pressing SELECT confirms the choice.
3 Pressing Esc exits the chosen menu.
By pressing Esc repeatedly, the cursor
is moved successively back to the
main menus.
Set-up mode
System diagnostic
Data log mode
Password Input
#
To Next Page
