5-2
BA
D24
en/us*
1.0
*
D24_1_0_500.fm
5
Operation
5.2
Accelerator actuation
Speed changeover
The vehicle
has two
speeds tha
t are selected
with the button
A
on the
joystick.
Keep the service brake
pressed to change over. The machine must
be at
a standstill.
Accelerator pedal
Accelerator peda
l
C
is located on the right in the leg room. Speed is
controlled continuously
with accelerator pedal
C
.
Fig. 99
A
Speed range selection
Indication
Speed range 1
Speed range 2
C
Fig. 100
Accelerator pedal
109
