Wacker Neuson DV100 User Manual

9-4 BA D24 en/us* 1.0 * D24_1_0_900.fm
9 Technical data
9.5 Tires
9.6 Steering system
9.7 Operating hydraulics
Tire type/size DV60 DV90 DV100
Tire size 405/70-20 (16/70-20) 41x18LL-22.5 500/60-22.5
Model MPT01 MPT03 Lawn 500
Tire pressure
Drive unit 2 bar (29 psi) 2.5 bar (36 psi) 2.8 bar (41 psi)
Loader unit 3.5 bar (51 psi) 4 bar (58 psi)
Load-bearing
capacity
Drive unit
3625 kg (7992 lbs)
2100 kg (4630 lbs) 3000 kg (6614 lbs)
Loader unit 3700 kg (8157 lbs) 5050 kg (11133 lbs)
DV60 DV90 DV100
Design Chassis articulation steering, hydraulic
Steering mode Hydraulic
Power supply Priority valve
Steering angle - design 29° 28.3°
Turning radius DV60 DV90 DV100
Front skip
Drive unit 5894 mm (19'-4'') 6585 mm (21'-7'')
Loader unit 5911 mm (19'-5'') 6547 mm (21'-6'')
Swivel skip
Drive unit 5894 mm (19'-4'') 6450 mm (21'-2'') --
Loader unit 5911 mm (19'-5'') 6412 mm (21'-0'') --
Work hydraulics DV60/DV90/DV100
Gear pump 31.9 cm
3
(1.95 in
3
)
Flow rate
60.6 l/min at 1900 rpm
(16.1 gal/min at 1900 rpm)
Max. operating pressure
(Work hydraulics)
240 bar (3481 psi)
Hydraulic oil radiator Yes
Hydraulic reservoir capacity
(Middle of sight glass)
48 l (12.7 gal)
Hydraulic reservoir capacity 60 l (15.9 gal)
Regulation method Throttle control
Filter Pressure filter
Braking system DV60/DV90/DV100
Service brake Mechanically actuated brake, no hydraulic support
Parking brake Hydro-mechanically actuated brake
