5-10 OM ET18/20/24 us 1.3 * et18_20_24b500.fm
5
Traveling signal (option)
A traveling signal sounds as soon as at least one of the tracks moves.
Accident hazard when traveling forward/backward.
Crushing hazard causing death or severe injury.
► Do not allow anyone to stay in the danger zone.
► Do not rely on the travel signal under any circumstances.
► If the traveling signal does not sound, stop machine operation
immediately and get in touch with a Wacker Neuson service
center (observe the relevant national regulations).
5.7 Wiper/wash system (option)
Front wiper
The switch is located on the right-hand switch panel.
Damage to wiper if the front window is raised.
► Do not actuate the wipers if the front window is raised.
Washer system
Damage to electric pump if the tank is empty.
► Do not actuate the washer system if the tank is empty.
Fig. 132: Wiper/wash system switch
40
Position Function
OFF Press switch 40 up
Wiper returns to base posi-
tion
1st position
Press switch 40 down to
the 1st position
Wiper in operation
Fig. 133: Wiper/wash system switch
40
Position Function
2nd posi-
tion
Press switch 40 down to
the 2nd position
Pump sprays washer water
on the window
