OM ET18/20/24 us 1.3 * et18_20_24w700.fm 7-23
7
7.6 Lubrication work
Preparing lubrication
1. Stop the machine on firm, level and horizontal ground.
2. Position the boom straight ahead at the center of the machine.
3. Lower the boom and the stabilizer blade to the ground.
4. Stop the engine.
5. Operate the control lever repeatedly to release the pressure in the
hydraulic system.
6. Raise the control lever base.
7. Remove the starting key and carry it with you.
8. Remove all loose objects from inside the machine.
9. Close the windows and the doors.
10.Close and lock all covers and doors.
11.Attach a warning label to the control elements (for example “Machine
being serviced, do not start”).
12.Wait at least 10 minutes after stopping the engine!
Fig. 240:Parking the machine
