5-30 OM ET18/20/24 us 1.3 * et18_20_24b510.fm
5
Lifting gear applications
Crushing hazard due to tipping over of machine.
Causes severe crushing or injury resulting in death.
► Observe chapter Safety/Safety instructions regarding
lifting gear applications.
► The authorized lift capacity specified in the stability table must
never be exceeded.
► If a bucket or attachment (hammer, etc.) is installed, the
weight of the attachment must be subtracted from the lift
capacity specified in the table.
► Use the machine for lifting gear applications only if the
mandatory lifting gear (load hook, for example) and safety
equipment (optical and acoustic warning devices (safe load
indicator), stability table, hydraulic hose burst valve, for
example) is installed, functional and enabled.
► Functional check of safe load indicator (see chapter “Safe
load indicator”).
► Do not tilt the upper carriage (Vertical Digging System option).
► The telescopic travel gear must be extended (option).
If the specified lift capacity is exceeded, possible damage to
property due to tipping over of the machine.
► The authorized lift capacity specified in the stability table must
never be exceeded.
In lifting gear applications, always switch on switch 38 for the safe load
indicator.
As soon as indicator light 32 illuminates and the warning sounds:
• Reduce the load until the indicator light goes out and the warning no
longer sounds.
Suitable equipment for fastening and securing loads must be available.
Fig. 167: Safe load indicator
38
