Wacker Neuson G 3.7A User Manual

G 3.7A;G/GS 5.6A;GS 8.5V;GS 9.7V Portable Generator Repair
wc_tx000208gb.fm 56
Control Panel (GS 8.5V and GS 9.7V models)
6.13 Choke Test
The resistance value of the choke is 7.5 ohms. To check the choke
carefully remove wires Z1 and Z3 from the choke assembly and
measure across choke tabs.
Ref. Description Ref. Description
a Main Circuit Breaker d Auto Idle Switch
b Hour meter e 120V 30A Twist-lock Receptacle
c 120V GFI Duplex Receptacle f 240V 20A Twist-lock Receptacle
c1 GFI test button g 120/240V Twist-lock Receptacle
c2 GFI reset button h 120V 20A Twist-lock Receptacle
w c _
g
r 0 0 0 5 5 9
0 0 0 0 0 0
I D L E
1 2 0
1 2 0
3 0 A
2 0 A
2 0 A
2 4 0
1 2 0 / 2 4 0
3 0 A
d
d 1
d 2
a 1
a 2
a b
c
e
f
g
h
c
c 1
c 2
