WarmFlow Air Source A-Series User Manual

Page 7
1.5 Construction
The Warmflow air source heat pumps are housed in a powder-coated galvanised metal casing
complete with enclosure box in which a cable entry terminal is mounted.
Figure 2 Typical Construction
Upon delivery, it is important that the unit is unpacked carefully and checked for any sign of
damage. If something is missing or damaged please report it to Warmflow immediately. The
units are secured to the shipping pallet using screws which must be removed.
NOTE: For coastal areas or other areas subjected to higher levels of corrosion, units can
be supplied with a Blygold coating applied to the evaporator to help protect it. Please
contact Warmflow for more details.
1.6 Supplied Components
Together with the unit, a number of additional components are supplied to aid installation. The
following items are supplied with each unit:
 1no. Y-strainer complete with 700μm Filter Gauze
 2no. 1” flexible hoses (1¼” to 1” adapter supplied with AS03)
 2no. 1” Male to Female Brass Elbows
 2no. 1” Isolating Ball Valves
 1no. DHW Cylinder Temperature Sensor
 4no. Anti-Vibration Mounts
 1no. Touchscreen Controller complete with wiring and wall mount
Upon delivery, it is important to check that all components are included. If something is missing
or damaged please report it to Warmflow immediately.
Fan
Feet Supports
Front Grill
Top Lid
Installer’s
Wiring Cover
Heating Flow
& Return
Connections
