「2」Installation
2 Installation
2.1 Installation Steps
1) Insert the software NcStudio CD to the CD driver of computer, and then double click the icon
for installation of the software;
2) Power off the computer, then open the chassis of host computer, then insert the control card to a
PCI slot and then fasten the rail block screw (if there is an extended flat cable, its rail block should
also be fixed), and then well cover the host computer chassis;
3) Power on the computer. The computer will find the new hardware-device and install its driver
automatically;
4) Double click the shortcut icon of NcStudio on the desktop; if it runs normally, installation is over. (If
the control system runs abnormally, please check whether the control card is well inserted and
whether the gold finger is clean)
2.2 Manually Update the Hardware Driver
1) Right click “My Computer”, select “Properties”, and then click “Device Manager”. Choose the
“CNC Adaptor” item, right click on it and select “Update Driver Software…” Users can begin
updating process according to the wizard. A dialog box as Fig. 2-1 will pop up.
Fig. 2-1 Hardware update wizard
2) Select “Install form a list of specific location (Advanced)”, click [Next] to continue. A dialog box as
Fig. 2-2 will pop up.
