Instructions for Assembly
Item number 116523-0000
We reserve the right to make technical
changes
Version 4 01.04.2014 Page 42/49
Opal Design II / Opal Design II LED
Item Designation Item Designation
1 Drop profile cover cap, left 49 Tilting part slider, right
2 Drop profile cover cap, right 50 Clamp profile member
3 Cover cap, SW 13 51 Headplate, left
4 Wall bracket cover cap, left 52 Headplate, right
5 Wall bracket cover cap, right 53 LED spotlight holder
6 Cover plug D10 54 LED spotlight
7 Transformer box cover 55 Slotted pan head screw DIN 7981-4.2x9.5
8 Axis for gear box D10x37.5 56 Fillister hex head screw ISO 7380-M4x20
9 Adapter 57 Oval head wood screw DIN 7995-4.5x80
10 Adapter locking device 58 Becker awning bracket, small
11 Arm stop 59 Mounting plate for rafter bracket
12 Arm bracket 60 Knurled nut with internal thread D10x46
13 Stop cam 61 Knurled nut with internal thread D10x59
14 Retaining plate 62 Knurled nut with internal thread D10x46
15 Eye screw 63 Washer DIN 1052-14-St-Zn
16 Drop profile for belt arm 64 Washer DIN 9021-13-A2
17 Drop profile support bracket, left 65 Washer DIN 125A-13-A2
18 Drop profile support bracket, right 66 Washer DIN 125A-8.4-A2
19 Belt arm, left 67 Plate dowel DIN 1052-C2 62/12
20 Belt arm, right 68
Slide rail Volant Plus drop profile support
bracket
21 Drive 69 Hexagonal nut DIN 934-M12
22 Clamping slider 70 Hexagonal nut DIN 934-M4
23 Sheet metal holder 71 Hexagonal nut DIN 934-M6
24 Faceplate, left 72 Hexagonal nut DIN 934-M8
25 Faceplate, right 73 Hexagon nut, self-locking DIN 985-M10
26 Blind rivet DIN 7337-A4x12 74 Hex socket head screw DIN 933-M12x20
27 Drop profile support bracket bushing 75 Hex socket head screw DIN 933-M12x35
28 Rafter bracket, left 76 Hex socket head screw DIN 933-M12x40
29 Ceiling angle 77 Hex socket head screw DIN 933-M12x140
30 Crescent-shaped cap seal 78
Countersunk sel
-tapping screw DIN7982-
St4.2x19
32 DUB flanged bush BB1212DUB 80 Countersunk hex head screw DIN 7991-M6x25
33 Spring D10x44.5 81 Crescent-shaped cap, left
34 Circlip DIN 127 B12 82 Crescent-shaped cap, right
35 Fischer wall plug S8 83 Pin for headplate
36 Sprag clutch 84 Support profile, gear box
37 Geiger ball ear 85 Support section clamp, 20 mm
38 Grub screw DIN913-M6x45-A2 86 Support profile
39 Grub screw DIN913-M8x20-A2 87 Fabric
40 Grub screw DIN913-M8x50-A2 88 Roller tube 78x1.25
41 Grub screw DIN913-M8x16 89 Roller tube insert D78 AD 12x16
42 Transformer holder, inside 90 Base plate
43 Hard cord edge, 5.2 mm 91 Wall bracket, 150 mm
44 Housing floor profile 92 Wall bracket top profile
45 Top of housing 93 Hex. socket head cap screw DIN6912 M8x25
46 Tilting member, left 94 Hex. socket head cap screw DIN912 M4x20
47 Tilting member, right 95 Hex. socket head cap screw DIN912 M8x25
48 Tilting part slider, left 96 Hex. socket head cap screw DIN912 M6x75
